456-2557 FILTER GP-ENGINE OIL -DUPLEXAN ATTACHMENT

Group No: 456-2557

Part Number	Part Name	Qty
1R0726	1 FILTER ELEMENT AS-ENGINE OIL (STANDARD EFFICIENCY)	4
2W1635	2 SPRING	1
2W1969	3 VALVE-BYPASS (OIL COOLER)	1
5543009	4 VALVE-CHECK	1
3J9173	5 BOLT-SPECIAL	1
5213763	6 TIE ROD	1
4W0090	7 BLOCK	1
4W0096	8 LEVER	1
4W0288	9 TUBE AS	1
4W0289	10 TUBE AS	1
4W0290	11 VALVE AS	1
4W0334	12 PLUNGER AS-BALL	1
4W0343	13 BRACKET	1
4W5592	14 COVER	1
7F0192	15 BOLT (3/8-16X2-IN)	6
7W3816	16 VALVE GP-FLUID CONTROL (DUPLEX OIL)	1
8N9482	17 SUPPORT-OIL FILTER	1
1118639	18 COVER-BYPASS VALVE	1
1551690	19 ADAPTER AS	2
1541581	RING-RETAINING	1
1570443	20 COVER AS	2
7N2043	DOWEL	1
2781082	21 HOUSING AS-FILTER (ENGINE OIL)	1
4V7412	BOSS (3/8-16-THD)	1
2781083	22 HOUSING AS-FILTER (AUXILIARY)	1
3923229	23 FILM-WARNING (VAPOR EXPLOSION)	2
4397480	24 PLATE	1
0026453	25 ELBOW	1
0L1143	26 BOLT (3/8-16X2.5-IN)	1
1653931	27 BOLT (3/8-16X1.75-IN)	2
0S1588	28 BOLT (3/8-16X1.25-IN)	8
0S1594	29 BOLT (3/8-16X1-IN)	1
0S1619	30 BOLT (3/8-16X3-IN)	2
0T0573	31 BOLT (3/8-16X2.75-IN)	3
1653931	32 BOLT (3/8-16X1.75-IN)	3
7X7875	33 ROD END	2
1B8706	34 KEY-WOODRUFF	1
1M0644	35 BOLT (3/8-16X2.25-IN)	3
2N3479	36 SCREW (10-24X0.5-IN)	4
2S5100	37 VALVE-MANUAL	2
3D9777	39 LEVER	1
4S5882	40 BOLT (1/2-13X7.25-IN)	2
5B9079	41 NUT-JAM (3/8-24-THD)	4
5M2894	42 WASHER-HARD (10.2X18.5X2.5-MM THK)	23
5P4624	43 BOLT (3/4-10X11.5-IN)	2
5P4892	44 SEAL-O-RING	4
5P8245	45 WASHER-HARD (13.5X25.5X3-MM THK)	1
6K9194	46 ELBOW	1
6V3907	47 SEAL-O-RING	6
6V5048	48 SEAL-O-RING	4
6V8001	49 SEAL-O-RING	1
6V8002	50 SEAL-O-RING	1
6V8823	51 WASHER-HARD (19.25X27X2-MM THK)	1
7D8793	52 ELBOW-FLARED	2
9K6540	54 WASHER-SPRING (0.63X1.25X0.04-IN THK)	1
9S4182	55 PLUG (7/16-20-THD)	4
9S8752	56 NUT-FULL (3/8-16-THD)	4
5328532	57 SEAL	4
0T0924	58 BOLT (3/8-24X1.5-IN)	2
