382-7794 LINES GP-WATER -AFTERCOOLERAN ATTACHMENT

Group No: 382-7794
Part NumberPart NameQty
39074701 ELBOW1
1W05132 ELBOW1
7C52303 TUBE AS1
8N03864 FLANGE1
8N19895 TUBE1
8N19906 FLANGE1
8N93907 ELBOW1
23010728 GASKET1
03079469 ELBOW2
165393110 BOLT (3/8-16X1.75-IN)4
1A202911 BOLT (3/8-16X1.125-IN)5
2A463912 BOLT (3/8-16X1.625-IN)1
4N132013 GASKET (ADAPTER)2
5M289414 WASHER-HARD (10.2X18.5X2.5-MM THK)11
6V145415 SEAL-O-RING2
6V506616 SEAL-O-RING2
6V902717 SEAL-O-RING2
165392518 BOLT (3/8-16X5.75-IN)2
7X057519 WASHER-HARD (10.2X22.5X5-MM THK)2
7X773120 PLUG-PIPE (3/4-14-THD)1
8T676521 PLUG-PIPE (1/4-18-THD)1
8T676722 PLUG-PIPE (3/8-18-THD)1
0S159423 BOLT (3/8-16X1-IN)2
0S161924 BOLT (3/8-16X3-IN)2
9S875225 NUT-FULL (3/8-16-THD)2
9X645826 WASHER-HARD (10.2X22.5X3-MM THK)2
091008127 SPACER (10.5X20X10-MM THK)1
264827228 CLAMP AS2
