System And Components
382-7638 REGULATOR GP-TEMPERATURE -AFTERCOOLERAN ATTACHMENT
Group No: 382-7638
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 3P6061 | 2 GASKET | 1 | |
| 4W0530 | 3 RING-RETAINING | 2 | |
| 4W0531 | 4 RETAINER | 4 | |
| 7C9597 | 5 FLANGE | 2 | |
| 7N6986 | 6 SUPPORT | 1 | |
| 8C7310 | 7 ADAPTER | 1 | |
| 1106995 | 8 PLATE | 1 | |
| 1109538 | 9 TUBE | 1 | |
| 1115052 | 10 BRACKET | 1 | |
| 1115056 | 11 CONNECTOR | 1 | |
| 1293083 | 12 ELBOW | 1 | |
| 1378219 | 13 ELBOW | 1 | |
| 1539481 | 14 CLAMP AS | 4 | |
| 1539963 | 15 RING | 2 | |
| 1874606 | 16 HOSE AS | 1 | |
| 2140731 | 17 BRACKET | 1 | |
| 2617296 | 18 BRACKET AS | 1 | |
| 2680028 | 19 TUBE | 1 | |
| 2884654 | 20 ELBOW | 1 | |
| 2926969 | 21 HOUSING & REGULATOR GP | 1 | |
| 3457620 | 22 BRACKET | 1 | |
| 0L1351 | 23 BOLT (3/8-16X0.875-IN) | 8 | |
| 0L2070 | 24 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1571 | 25 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1591 | 26 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 27 BOLT (3/8-16X1-IN) | 8 | |
| 0T0055 | 28 BOLT (3/8-16X4.25-IN) | 2 | |
| 0T0065 | 29 BOLT (3/8-16X3.5-IN) | 2 | |
| 1932120 | 30 GROMMET | 3 | |
| 1A2029 | 31 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 32 BOLT (1/2-13X2.75-IN) | 2 | |
| 1C2251 | 33 BOLT (3/8-16X1.87-IN) | 2 | |
| 2A4639 | 34 BOLT (3/8-16X1.625-IN) | 1 | |
| 2M0849 | 35 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 3B1915 | 36 BOLT (3/8-16X1.375-IN) | 1 | |
| 3J1907 | 37 SEAL-O-RING | 1 | |
| 3V3308 | 38 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 4F7387 | 39 SEAL-O-RING | 1 | |
| 4W4076 | 40 ELBOW | 1 | |
| 5B0841 | 41 BOLT (5/8-18X1.75-IN) | 4 | |
| 5B2638 | 42 BOLT (3/8-16X5.25-IN) | 2 | |
| 5B4399 | 43 SEAL-O-RING | 1 | |
| 5M2894 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 6H1717 | 45 BOLT (1/2-13X1.125-IN) | 1 | |
| 6J2680 | 46 SEAL-O-RING | 4 | |
| 6V1867 | 47 CLIP (SLOT) | 3 | |
| 6V1868 | 48 CLIP (TAB) | 3 | |
| 6V8397 | 49 SEAL-O-RING | 1 | |
| 6V9829 | 50 CAP (ORFS) | 1 | |
| 6V9843 | 51 TEE | 1 | |
| 7W6492 | 52 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8C6870 | 53 CONNECTOR | 1 | |
| 8S9191 | 54 BOLT (3/8-16X4-IN) | 2 | |
| 8T1919 | 55 SEAL-O-RING | 4 | |
| 9L9132 | 56 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9R5008 | 57 SPACER (11X20X6-MM THK) | 1 | |
| 9S4191 | 58 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 59 NUT-FULL (3/8-16-THD) | 12 | |
| 9X6458 | 60 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
