489-3869 WIRING GP-ENGINEAN ATTACHMENT

Group No: 489-3869
Part NumberPart NameQty
7K11811 STRAP-CABLE29
9G51272 BREATHER (ATMOSPHERIC)1
9X02633 ADAPTER2
9X67724 STRAP-CABLE65
10222405 SENSOR GP-TEMPERATURE (3-PIN)(ENGINE COOLANT)2
11136846 HOSE AS1
16199267 SENSOR GP-PRESSURE (ATMOSPHERIC AIR)1
16199267A SENSOR GP-PRESSURE (TURBOCHARGER INLET, RH)1
16199267B SENSOR GP-PRESSURE (TURBOCHARGER INLET, LH)1
16199267C SENSOR GP-PRESSURE (CRANKCASE)1
19467248 SENSOR GP-PRESSURE (TURBOCHARGER OUTLET)1
19467259 SENSOR GP-PRESSURE (UNFILTERED FUEL)1
19467259A SENSOR GP-PRESSURE (FILTERED FUEL)1
19467259B SENSOR GP-PRESSURE (FILTERED OIL)1
19467259C SENSOR GP-PRESSURE (UNFILTERED OIL)1
253734010 HARNESS AS-ENGINE (ENGINE CONTROL MODULE)1
261684711 ADAPTER2
273504112 SENSOR GP-SPEED (ENGINE TIMING)1
415243213 SENSOR GP-TEMPERATURE (EXHAUST)(TURBOCHARGER, LH)1
415243213A SENSOR GP-TEMPERATURE (EXHAUST)(TURBOCHARGER, RH)1
452035514 HARNESS AS-ENGINE (WIRING)2
001944015 CONNECTOR1
0S050916 BOLT (3/8-16X0.75-IN)6
165393117 BOLT (3/8-16X1.75-IN)2
0S159018 BOLT (3/8-16X2-IN)1
0S159419 BOLT (3/8-16X1-IN)7
117006720 ELBOW4
4P706821 BRACKET1
352396822 CLIP (LADDER)4
3A369223 CLIP2
3B191524 BOLT (3/8-16X1.375-IN)1
3B655225 ELBOW-PIPE2
3K036026 SEAL-O-RING2
3Y810027 BOLT (3/8-16X0.87-IN)4
4P742928 CLIP4
4P758129 CLIP (LADDER)7
4P813430 CLIP (LADDER)54
5M289431 WASHER-HARD (10.2X18.5X2.5-MM THK)26
5P342632 ELBOW1
6V504833 SEAL-O-RING17
9M459434 SPACER (0.406X0.875X0.75-IN THK)3
9X026235 ADAPTER3
0L207036 BOLT (3/8-16X2.25-IN)4
0S162037 BOLT (1/2-13X0.75-IN)1
5P824538 WASHER-HARD (13.5X25.5X3-MM THK)1
6W667239 SPACER (10.5X20X38-MM THK)4
9S875240 NUT-FULL (3/8-16-THD)1
