System And Components
432-1171 LINES GP-WATER -LOWERS/N 9G51-UP
Group No: 432-1171
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0386 | 1 FLANGE | 1 | |
| 8N1989 | 2 TUBE | 1 | |
| 1419285 | 3 ELBOW | 1 | |
| 2301072 | 4 GASKET | 1 | |
| 3907470 | 5 ELBOW | 1 | |
| 2648272 | 6 CLAMP AS | 2 | |
| 0910081 | 7 SPACER (10.5X20X10-MM THK) | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 2 | |
| 0S1619 | 9 BOLT (3/8-16X3-IN) | 2 | |
| 1A2029 | 10 BOLT (3/8-16X1.125-IN) | 2 | |
| 2A4639 | 11 BOLT (3/8-16X1.625-IN) | 1 | |
| 4N1320 | 12 GASKET (ADAPTER) | 1 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6V1454 | 14 SEAL-O-RING | 2 | |
| 6V5066 | 15 SEAL-O-RING | 1 | |
| 9S8752 | 16 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
