System And Components
382-7798 REGULATOR GP-TEMPERATURE -AFTERCOOLERS/N 9G51-UP
Group No: 382-7798
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1204344 | 1 ADAPTER | 1 | |
| 1N3872 | 2 SUPPORT | 1 | |
| 3P6061 | 3 GASKET | 1 | |
| 4W0530 | 4 RING-RETAINING | 6 | |
| 4W0531 | 5 RETAINER | 12 | |
| 7C9597 | 6 FLANGE | 4 | |
| 1106995 | 7 PLATE | 1 | |
| 1109538 | 8 TUBE | 1 | |
| 1115052 | 9 BRACKET | 1 | |
| 1115056 | 10 CONNECTOR | 1 | |
| 1142040 | 11 ELBOW | 1 | |
| 1207425 | 12 FLANGE | 1 | |
| 1212023 | 13 TUBE | 1 | |
| 1221680 | 14 BRACKET | 1 | |
| 1293083 | 15 ELBOW | 1 | |
| 1430507 | 16 TUBE | 1 | |
| 1430508 | 17 BRACKET | 1 | |
| 4947440 | 18 BRACKET | 1 | |
| 2166217 | 19 HOUSING & REGULATOR GP (AFTERCOOLER) | 1 | |
| 2301072 | 20 GASKET | 1 | |
| 0L1351 | 21 BOLT (3/8-16X0.875-IN) | 4 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 6 | |
| 0S1588 | 23 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 1 | |
| 1653929 | 25 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 9 | |
| 0T0065 | 27 BOLT (3/8-16X3.5-IN) | 2 | |
| 1965052 | 28 CLIP (SLOT) | 4 | |
| 1965053 | 29 CLIP (TAB) | 4 | |
| 1A2029 | 30 BOLT (3/8-16X1.125-IN) | 6 | |
| 1A5822 | 31 BOLT (1/2-13X2.75-IN) | 2 | |
| 1C2251 | 32 BOLT (3/8-16X1.87-IN) | 2 | |
| 2M0849 | 33 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 2V4387 | 34 SPACER (10.312X25.4X23.11-MM THK) | 1 | |
| 3B1915 | 35 BOLT (3/8-16X1.375-IN) | 7 | |
| 8M9024 | 36 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 4F7387 | 37 SEAL-O-RING | 1 | |
| 5B0841 | 38 BOLT (5/8-18X1.75-IN) | 4 | |
| 5B2638 | 39 BOLT (3/8-16X5.25-IN) | 2 | |
| 5B4399 | 40 SEAL-O-RING | 1 | |
| 5M2894 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 6H1717 | 42 BOLT (1/2-13X1.125-IN) | 1 | |
| 6H6698 | 43 COVER | 1 | |
| 6J2680 | 44 SEAL-O-RING | 6 | |
| 7W6492 | 45 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8T1919 | 46 SEAL-O-RING | 6 | |
| 9S8752 | 48 NUT-FULL (3/8-16-THD) | 11 | |
| 9X6458 | 49 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
