System And Components
382-7799 REGULATOR GP-TEMPERATURE -AFTERCOOLERS/N 9G51-UP
Group No: 382-7799
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 3J1907 | 2 SEAL-O-RING | 1 | |
| 3P6061 | 3 GASKET | 1 | |
| 4W0530 | 4 RING-RETAINING | 4 | |
| 4W0531 | 5 RETAINER | 8 | |
| 5H3124 | 6 SPACER (0.406X1X0.625-IN THK) | 1 | |
| 7C9597 | 7 FLANGE | 1 | |
| 9S9635 | 8 JOINT AS-TUBE | 1 | |
| 1106995 | 9 PLATE | 1 | |
| 1109538 | 10 TUBE | 1 | |
| 1115052 | 11 BRACKET | 1 | |
| 1115056 | 12 CONNECTOR | 1 | |
| 1142040 | 13 ELBOW | 1 | |
| 1293083 | 14 ELBOW | 1 | |
| 1622737 | 15 ELBOW | 1 | |
| 1965052 | 16 CLIP (SLOT) | 4 | |
| 1965053 | 17 CLIP (TAB) | 4 | |
| 1995609 | 18 TUBE | 1 | |
| 2022123 | 19 TUBE | 1 | |
| 2140731 | 20 BRACKET | 1 | |
| 2166217 | 21 HOUSING & REGULATOR GP (AFTERCOOLER) | 1 | |
| 2572007 | 22 PLATE | 1 | |
| 0L1351 | 23 BOLT (3/8-16X0.875-IN) | 8 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 3 | |
| 0S1591 | 25 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 8 | |
| 0T0065 | 27 BOLT (3/8-16X3.5-IN) | 2 | |
| 0T0573 | 28 BOLT (3/8-16X2.75-IN) | 1 | |
| 1A2029 | 29 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 30 BOLT (1/2-13X2.75-IN) | 2 | |
| 1C2251 | 31 BOLT (3/8-16X1.87-IN) | 2 | |
| 2M0849 | 32 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 2V4387 | 33 SPACER (10.312X25.4X23.11-MM THK) | 2 | |
| 3B1915 | 34 BOLT (3/8-16X1.375-IN) | 1 | |
| 3D4067 | 35 SPACER (0.438X0.75X1.688-IN THK) | 1 | |
| 3K0360 | 36 SEAL-O-RING | 1 | |
| 3V3308 | 37 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 4F7387 | 38 SEAL-O-RING | 1 | |
| 5B0841 | 39 BOLT (5/8-18X1.75-IN) | 4 | |
| 5B2638 | 40 BOLT (3/8-16X5.25-IN) | 2 | |
| 5B4399 | 41 SEAL-O-RING | 1 | |
| 5M2894 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6H1717 | 43 BOLT (1/2-13X1.125-IN) | 1 | |
| 6J2680 | 44 SEAL-O-RING | 3 | |
| 7W6492 | 45 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8S9191 | 46 BOLT (3/8-16X4-IN) | 2 | |
| 8T1919 | 47 SEAL-O-RING | 4 | |
| 9L9132 | 48 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S4191 | 49 PLUG (9/16-18-THD) | 1 | |
| 9S8005 | 50 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 51 NUT-FULL (3/8-16-THD) | 6 | |
| 9X6458 | 52 WASHER-HARD (10.2X22.5X3-MM THK) | 9 |
