System And Components
378-8170 GUARD GP-COUPLINGS/N 9G81-UP
Group No: 378-8170
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P7115 | 1 GROMMET AS | 6 | |
| 2N3385 | 2 NUT-CLIP (3/8-16-THD) | 4 | |
| 3L9689 | 3 WASHER (10.5X25.4X5-MM THK) | 4 | |
| 3508624 | 4 PLATE | 2 | |
| 3512245 | 5 BOLT-SPECIAL (1/2-13X2-IN) | 12 | |
| 3519006 | 6 BOSS-WELD | 12 | |
| 3554899 | 7 BRACKET | 6 | |
| 3564973 | 8 GUARD AS-COUPLING | 1 | |
| 2A4639 | 9 BOLT (3/8-16X1.625-IN) | 6 | |
| 2K4973 | 10 LOCKNUT (3/8-16-THD) | 4 | |
| 3B4506 | 11 LOCKWASHER | 4 | |
| 3F1417 | 12 WASHER (10.3X30.2X3-MM THK) | 6 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5S7382 | 14 BOLT (3/8-16X1.375-IN) | 4 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 9L9132 | 16 WASHER-HARD (10.2X25.5X2.5-MM THK) | 6 | |
| 9S8752 | 17 NUT-FULL (3/8-16-THD) | 6 |
