506-9995 RADIATOR & MOUNTING GPS/N 9G81-UP

Group No: 506-9995

Part Number	Part Name	Qty
4P3117	1 VALVE-BALL	2
4W0530	2 RING-RETAINING	2
4W0531	3 RETAINER	4
7W1506	4 ELBOW	1
9Y7645	5 GUARD AS-FAN	2
1F0750	NUT-WELD (3/8-16-THD)	11
6N8599	CLIP	3
1209678	6 BRACKET	2
1265613	7 FLANGE	2
3387181	8 BRACKET AS	2
3669470	9 PLATE AS	2
4982278	10 RADIATOR GP	1
1984781	11 WASHER-HARD (22X40X10-MM THK)	18
2257003	12 SEAL-O-RING	1
2673507	13 WASHER-HARD (26X47X12-MM THK)	12
2890272	14 BOLT (3/4-10X5-IN)	6
3B7749	15 NIPPLE-PIPE	2
4L6454	16 BOLT (3/8-16X1-IN)	26
4L9337	17 BOLT (3/8-16X1.5-IN)	2
5P1075	18 WASHER-HARD (10.2X22.5X3-MM THK)	22
5P2424	19 BOLT (1/2-13X2.25-IN)	1
6V1581	20 CLIP (SLOT)	2
6V1582	21 CLIP (TAB)	2
6V8182	22 NUT (3/4-10-THD)	12
6V8188	23 NUT (1/2-13-THD)	8
6V8801	24 NUT (3/8-16-THD)	2
2993436	25 BOLT (7/8-9X3.5-IN)	6
7X0449	26 NUT-FULL (7/8-9-THD)	6
7X3391	27 WASHER-HARD (13.5X32X6-MM THK)	1
8C7323	28 BOLT (3/8-16X6-IN)	2
8T1919	29 SEAL-O-RING	2
8T4223	30 WASHER-HARD (13.5X25.5X3-MM THK)	1
8T4835	31 BOLT (1/2-13X2-IN)	7
8T4896	32 WASHER-HARD (10.2X18.5X2.5-MM THK)	8
8T4994	33 WASHER-HARD (20X36.5X3.5-MM THK)	12
8T8917	34 BOLT (1/2-13X1.25-IN)	1
8T8924	35 BOLT (3/4-10X2.5-IN)	12
9B7237	36 BOLT (3/8-16X1.25-IN)	5
9Y6893	37 GASKET	2
3E6508	38 FILM-IDENTIFICATION (CAT)	1
2253227	39 FILM-WARNING (HOT SURFACE)	2
2254256	40 FILM-WARNING (HOT FLUID UNDER PRESSURE, U.S.)	1
