System And Components
491-7067 REGULATOR GP-TEMPERATURE -AFTERCOOLERS/N 9G81-UP
Group No: 491-7067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 3P6061 | 2 GASKET | 1 | |
| 4W0530 | 3 RING-RETAINING | 2 | |
| 4W0531 | 4 RETAINER | 4 | |
| 7C9597 | 5 FLANGE | 2 | |
| 7N6986 | 6 SUPPORT | 1 | |
| 1106995 | 7 PLATE | 1 | |
| 1109538 | 8 TUBE | 1 | |
| 1115052 | 9 BRACKET | 1 | |
| 1115056 | 10 CONNECTOR | 1 | |
| 1142040 | 11 ELBOW | 1 | |
| 1293083 | 12 ELBOW | 1 | |
| 1378219 | 13 ELBOW | 1 | |
| 1539481 | 14 CLAMP AS | 4 | |
| 1539963 | 15 RING | 2 | |
| 2140731 | 16 BRACKET | 1 | |
| 2617296 | 17 BRACKET AS | 1 | |
| 2680028 | 18 TUBE | 1 | |
| 2828537 | 19 HOUSING & REGULATOR GP (THERMOSTATIC) | 1 | |
| 3457620 | 20 BRACKET | 1 | |
| 0L1351 | 21 BOLT (3/8-16X0.875-IN) | 8 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 2 | |
| 1653931 | 23 BOLT (3/8-16X1.75-IN) | 4 | |
| 1653929 | 24 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 8 | |
| 0T0055 | 26 BOLT (3/8-16X4.25-IN) | 2 | |
| 0T0065 | 27 BOLT (3/8-16X3.5-IN) | 2 | |
| 1932120 | 28 GROMMET | 3 | |
| 1A2029 | 29 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 30 BOLT (1/2-13X2.75-IN) | 1 | |
| 1C2251 | 31 BOLT (3/8-16X1.87-IN) | 2 | |
| 2A4639 | 32 BOLT (3/8-16X1.625-IN) | 1 | |
| 2M0849 | 33 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 3B1915 | 34 BOLT (3/8-16X1.375-IN) | 1 | |
| 3J1907 | 35 SEAL-O-RING | 1 | |
| 3V3308 | 36 WASHER-HARD (10.2X20.5X2.5-MM THK) | 10 | |
| 4F7387 | 37 SEAL-O-RING | 1 | |
| 5B0841 | 38 BOLT (5/8-18X1.75-IN) | 4 | |
| 5B2638 | 39 BOLT (3/8-16X5.25-IN) | 2 | |
| 5B4399 | 40 SEAL-O-RING | 1 | |
| 5M2894 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6H1717 | 42 BOLT (1/2-13X1.125-IN) | 1 | |
| 6J2680 | 43 SEAL-O-RING | 4 | |
| 6V1867 | 44 CLIP (SLOT) | 3 | |
| 6V1868 | 45 CLIP (TAB) | 3 | |
| 7W6492 | 46 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8S9191 | 47 BOLT (3/8-16X4-IN) | 2 | |
| 8T1919 | 48 SEAL-O-RING | 4 | |
| 8T6767 | 49 PLUG-PIPE (3/8-18-THD) | 1 | |
| 9L9132 | 50 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9R5008 | 51 SPACER (11X20X6-MM THK) | 1 | |
| 9S4191 | 52 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 53 NUT-FULL (3/8-16-THD) | 12 | |
| 9X6458 | 54 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
