System And Components
457-7568 LINES GP-FUEL INJECTIONS/N 9G81-UP
Group No: 457-7568
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0693 | 1 CLAMP AS | 4 | |
| 6V4363 | 2 ELBOW | 1 | |
| 7C7677 | 3 TUBE AS | 12 | |
| 7C7678 | 4 TUBE AS | 12 | |
| 7C7682 | 5 ADAPTER-FUEL MANIFOLD (RH) | 1 | |
| 7C7683 | 6 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 7E3921 | 7 VALVE-CHECK (FUEL INJECTION) | 1 | |
| 7W2122 | 8 CONNECTOR-PORT | 24 | |
| 8N6210 | 9 BRACKET-LINE SUPPORT | 1 | |
| 8N6211 | 10 PLATE-LINE SUPPORT | 1 | |
| 9N4053 | 11 SPRING | 1 | |
| 1113389 | 12 TUBE AS | 1 | |
| 1145477 | 13 PLUNGER-VALVE | 1 | |
| 1569753 | 14 MANIFOLD GP-FUEL (RH) | 1 | |
| 1569754 | 15 MANIFOLD GP-FUEL (LH) | 1 | |
| 2372713 | 16 TUBE AS | 1 | |
| 5P4900 | 17 ELBOW-FLARED | 1 | |
| 0L2070 | 18 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1590 | 19 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 20 BOLT (3/8-16X1-IN) | 1 | |
| 0T0065 | 21 BOLT (3/8-16X3.5-IN) | 2 | |
| 1D4539 | 22 BOLT (5/16-18X2.5-IN) | 1 | |
| 1D4541 | 23 BOLT (5/16-18X3-IN) | 1 | |
| 2147568 | 24 SEAL-O-RING | 24 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5S0003 | 27 NUT (5/16-18-THD) | 1 | |
| 6B6205 | 28 SPACER (0.438X0.875X1.281-IN THK) | 2 | |
| 2385081 | 29 SEAL-O-RING | 2 | |
| 3095130 | 30 PLUG AS | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 7N6806 | 31 SEAL-RECTANGULAR | 4 | |
| 3650578 | 32 CONNECTOR AS | 1 | |
| 9M4584 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 9M1974 | 33 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 3650576 | 34 CONNECTOR AS | 2 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 |
