System And Components
419-3856 RADIATOR & MOUNTING GPS/N 9H21-UP
Group No: 419-3856
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P3117 | 1 VALVE-BALL | 2 | |
| 4W0530 | 2 RING-RETAINING | 2 | |
| 4W0531 | 3 RETAINER | 4 | |
| 7W1506 | 4 ELBOW | 1 | |
| 9Y7645 | 5 GUARD AS-FAN | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 11 | |
| 6N8599 | CLIP | 3 | |
| 1209678 | 6 BRACKET | 1 | |
| 1265613 | 7 FLANGE | 2 | |
| 3387181 | 8 BRACKET AS | 2 | |
| 4982279 | 9 RADIATOR GP | 1 | |
| 1984781 | 10 WASHER-HARD (22X40X10-MM THK) | 24 | |
| 2257003 | 11 SEAL-O-RING | 1 | |
| 2515715 | 12 BOLT (3/4-10X4.25-IN) | 6 | |
| 2673507 | 13 WASHER-HARD (26X47X12-MM THK) | 12 | |
| 3B7749 | 14 NIPPLE-PIPE | 2 | |
| 4L6454 | 15 BOLT (3/8-16X1-IN) | 26 | |
| 4L9337 | 16 BOLT (3/8-16X1.5-IN) | 1 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 22 | |
| 6V1581 | 18 CLIP (SLOT) | 1 | |
| 6V1582 | 19 CLIP (TAB) | 1 | |
| 6V8182 | 20 NUT (3/4-10-THD) | 18 | |
| 6V8188 | 21 NUT (1/2-13-THD) | 8 | |
| 6V8801 | 22 NUT (3/8-16-THD) | 1 | |
| 7X0386 | 23 BOLT (7/8-9X3.5-IN) | 6 | |
| 7X0449 | 24 NUT-FULL (7/8-9-THD) | 6 | |
| 7X3391 | 25 WASHER-HARD (13.5X32X6-MM THK) | 1 | |
| 8C7323 | 26 BOLT (3/8-16X6-IN) | 2 | |
| 8T1919 | 27 SEAL-O-RING | 2 | |
| 8T4835 | 28 BOLT (1/2-13X2-IN) | 8 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T4994 | 30 WASHER-HARD (20X36.5X3.5-MM THK) | 12 | |
| 8T8917 | 31 BOLT (1/2-13X1.25-IN) | 1 | |
| 8T8924 | 32 BOLT (3/4-10X2.5-IN) | 12 | |
| 9B7237 | 33 BOLT (3/8-16X1.25-IN) | 5 | |
| 9Y6893 | 34 GASKET | 2 |
