System And Components
420-9674 MOUNTING GP-WIRINGS/N X3F1-UP
Group No: 420-9674
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3482879 | 1 WIRING GP-GENERATOR | 1 | |
| 4P7581 | 2 CLIP (LADDER) | 2 | |
| 1325789 | 3 CLIP (LADDER) | 7 | |
| 3S2093 | 4 STRAP-CABLE | 30 | |
| 9N1394 | 5 BRACKET | 2 | |
| 5M3062 | 6 BOLT (3/8-16X0.75-IN) | 10 | |
| 8T4896 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 6V8801 | 8 NUT (3/8-16-THD) | 8 | |
| 3883285 | 9 BOX GP-JUNCTION | 1 | |
| 7X0343 | 10 BOLT (5/8-11X1.25-IN) | 2 | |
| 8T4122 | 11 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 3368561 | 12 KIT-THERMOSTAT | 1 | |
| 3S8664 | 13 CLIP | 4 | |
| 5C7261 | 14 NUT (M8X1.25-THD) | 2 | |
| 3631845 | 15 HARNESS AS-CEM | 1 | |
| 9B7237 | 16 BOLT (3/8-16X1.25-IN) | 3 | |
| 5P2369 | 17 CLIP (LOOP) | 1 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2042518 | 19 SENSOR GP-LIQUID LEVEL (COOLANT LOSS) | 1 | |
| 2644297 | 20 SENSOR AS-TEMPERATURE (2-PIN)(PASSIVE DATA BOOSTER) | 1 | |
| 2385080 | 21 SEAL-O-RING | 1 | |
| 5P8874 | 22 ADAPTER | 1 | |
| 1043045 | 23 BOLT-FLANGE HEAD (5/16-18X0.625-IN) | 1 |
