System And Components
325-5706 CONTROL GP-AIR STARTING (CHG -10)Type 2
Group No: 325-5706
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V5956 | 1 HOSE AS | 1 | |
| 3E2319 | 2 VALVE-BALL | 1 | |
| 3J7355 | 3 UNION-FLARED | 1 | |
| 3N7281 | 4 HOSE AS | 1 | |
| 3P0764 | 5 PLUG | 1 | |
| 3V6153 | 6 HOSE AS | 1 | |
| 5G3699 | 7 HOSE AS | 1 | |
| 5N7131 | 9 FLANGE | 1 | |
| 6L7028 | 11 JOINT AS | 1 | |
| 9X7535 | SEAL | 2 | |
| 7C0370 | 12 TUBE AS | 1 | |
| 7C0371 | 13 TUBE AS | 1 | |
| 7C0372 | 14 BRACKET | 2 | |
| 7D4754 | 15 BUSHING | 1 | |
| 8N8471 | 16 CLAMP-TUBE | 2 | |
| 8Q9642 | 17 ELBOW | 1 | |
| 0332177 | 18 TEE-PIPE | 1 | |
| 1339637 | 19 BRACKET | 1 | |
| 1387205 | 20 CLAMP-PIPE | 2 | |
| 1893269 | 21 HOSE AS | 1 | |
| 2163020 | 22 HOSE AS | 1 | |
| 2461245 | 23 FITTING | 1 | |
| 2680161 | 24 HOSE AS | 1 | |
| 2794506 | 25 FITTING | 1 | |
| 3176510 | 26 FLANGE | 1 | |
| 3215582 | 27 HOSE AS | 1 | |
| 3282203 | 28 BRACKET AS | 1 | |
| 3287438 | 29 ADAPTER-TEE | 1 | |
| 3490734 | 30 CROSS-PIPE | 1 | |
| 3554516 | 31 PIPE | 2 | |
| 4485598 | 32 SWITCH AS-PRESSURE (AIR) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 9X1813 | SLEEVE (15-CM) | ||
| 0307946 | 33 ELBOW | 2 | |
| 0520572 | 34 TEE-SWIVEL | 1 | |
| 0676495 | 35 ELBOW-FLARED | 1 | |
| 0S1587 | 36 BOLT (1/2-13X1.75-IN) | 8 | |
| 0S1588 | 37 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 38 BOLT (3/8-16X1-IN) | 2 | |
| 0S1615 | 39 BOLT (1/4-20X0.75-IN) | 2 | |
| 0S1619 | 40 BOLT (3/8-16X3-IN) | 4 | |
| 1P4579 | 41 FLANGE-HALF | 2 | |
| 2877338 | 42 BUSHING-REDUCER | 1 | |
| 3E9865 | 43 LOCKNUT (1/4-20-THD) | 4 | |
| 3J5389 | 44 PLUG (EXTERNAL) | 2 | |
| 2147566 | 45 SEAL-O-RING | 2 | |
| 3V3308 | 46 WASHER-HARD (10.2X20.5X2.5-MM THK) | 8 | |
| 2343544 | 47 SEAL-O-RING | 1 | |
| 4S6399 | 48 CONNECTOR | 4 | |
| 5B7660 | 49 BUSHING-REDUCER | 2 | |
| 5P0537 | 50 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 5P8245 | 51 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 6B6205 | 52 SPACER (0.438X0.875X1.281-IN THK) | 4 | |
| 6D3479 | 53 CLIP (LOOP)(LOOP) | 2 | |
| 6F7699 | 54 BUSHING-REDUCER | 1 | |
| 6K1972 | 55 ELBOW-FLARED | 3 | |
| 6V4589 | 56 SEAL-O-RING | 1 | |
| 7K6462 | 57 ELBOW | 2 | |
| 7K9197 | 58 ELBOW | 3 | |
| 8N8451 | 59 GASKET | 1 | |
| 8Q9643 | 60 FITTING | 2 | |
| 8S4711 | 61 BOLT (1/4-20X4.5-IN) | 4 | |
| 8T6765 | 62 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9B3523 | 63 BUSHING | 1 | |
| 9S8752 | 64 NUT-FULL (3/8-16-THD) | 1 | |
| 9X8873 | 65 BOLT (1/2-13X2.25-IN) | 2 |
