System And Components
476-1411 CAMSHAFT GPS/N E2L1-UP; E2P1-UP; E2X1-UP
Group No: 476-1411
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W6664 | 1 PLATE AS-TIMING | 2 | |
| 7N3216 | 2 SPACER (35.035X84X12-MM THK) | 2 | |
| 7N3218 | 3 WASHER-THRUST | 2 | |
| 2503444 | 4 FILM-INFORMATION (STANDARD ROTATION) | 1 | |
| 4761407 | 5 CAMSHAFT-FRONT (RH) | 1 | |
| 4761408 | 6 CAMSHAFT AS-FRONT (LH) | 1 | |
| 4N1650 | DOWEL | 1 | |
| 4761409 | 7 CAMSHAFT AS-REAR (RH) | 1 | |
| 4N1650 | DOWEL | 1 | |
| 4761410 | 8 CAMSHAFT AS-REAR (LH) | 1 | |
| 5B5821 | DOWEL | 1 | |
| 0L1351 | 9 BOLT (3/8-16X0.875-IN) | 4 | |
| 0S0509 | 10 BOLT (3/8-16X0.75-IN) | 2 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P0076 | 12 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 16 |
