System And Components
141-1809 BOX GP-GENERATOR CONNECTIONS/N 9RZ1-UP
Group No: 141-1809
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T0023 | 1 BOLT-HEAD LOCKING (5/16-18X1-IN) | 60 | |
| 1159550 | 2 BRACKET | 1 | |
| 1169991 | 3 COVER GP-EXTENSION BOX | 1 | |
| 1219641 | 4 BRACKET | 1 | |
| 1281479 | 5 FRAME GP-GENERATOR CONNECTION | 1 | |
| 1283344 | 6 PANEL (SIDE) | 2 | |
| 1287260 | 7 PANEL AS | 1 | |
| 4F8711 | PLUG-BUTTON | 2 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5V0770 | BOLT-CARRIAGE (1/4-20X0.74-IN) | 8 | |
| 6V8185 | NUT (1/4-20-THD) | 8 | |
| 1287261 | 8 PANEL-BACK | 1 | |
| 1287262 | 9 SCREEN AS-AIR (INLET) | 1 | |
| 1287263 | 10 PANEL-LOWER | 1 | |
| 1414812 | 11 BRACKET-MOUNTING (RH) | 1 | |
| 1414813 | 12 BRACKET-MOUNTING (LH) | 1 | |
| 5M3062 | 13 BOLT (3/8-16X0.75-IN) | 6 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 18 | |
| 8T9364 | 15 BOLT (1/4-20X0.625-IN) | 5 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 8T4205 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 5 |
