System And Components
357-3045 BOX GP-GENERATOR CONNECTIONFOR USE WITH 820-FRAME GENERATORS
Group No: 357-3045
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3573044 | 1 PANEL-LOWER | 1 | |
| 8T0023 | 2 BOLT-HEAD LOCKING (5/16-18X1-IN) | 60 | |
| 1159550 | 3 BRACKET | 1 | |
| 1169991 | 4 COVER GP-EXTENSION BOX | 1 | |
| 1219641 | 5 BRACKET | 1 | |
| 1287260 | 7 PANEL AS | 1 | |
| 4F8711 | PLUG-BUTTON | 2 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5V0770 | BOLT-CARRIAGE (1/4-20X0.74-IN) | 8 | |
| 6V8185 | NUT (1/4-20-THD) | 8 | |
| 1287262 | 8 SCREEN AS-AIR (INLET) | 1 | |
| 1414812 | 9 BRACKET-MOUNTING (RH) | 1 | |
| 1414813 | 10 BRACKET-MOUNTING (LH) | 1 | |
| 1552001 | 11 RETAINER | 16 | |
| 3089260 | 12 FASTENER-SPECIAL | 16 | |
| 3573041 | 13 FRAME GP-GENERATOR CONNECTION | 1 | |
| 3573042 | 14 PANEL | 2 | |
| 3573043 | 15 PANEL-BACK | 1 | |
| 0S0509 | 16 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 18 | |
| 0S1616 | 18 BOLT (1/4-20X1-IN) | 2 | |
| 2A0762 | 19 BOLT (1/4-20X0.625-IN) | 3 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 5P0537 | 21 WASHER-HARD (7.2X14.5X2-MM THK) | 5 |
