System And Components
377-2867 PANEL GP-CIRCUIT BREAKERS/N PPE1-UP
Group No: 377-2867
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1F2622 | 1 WASHER (0.156X0.97X0.049-IN THK) | 4 | |
| 4P1539 | 2 BUSHING-TERMINAL | 1 | |
| 4P6748 | 3 BUSHING-TERMINAL | 1 | |
| 8N9300 | 4 MOUNT AS | 4 | |
| 9Y2921 | 5 RELAY (24-VOLT)(PANEL) | 1 | |
| 5320675 | 6 BUSHING | 2 | |
| 1251302 | 7 SWITCH GP-MAGNETIC (24-VOLT)(STARTING MOTOR) | 2 | |
| 1251302 | 7A SWITCH GP-MAGNETIC (24-VOLT)(AIR SHUTOFF) | 1 | |
| 2022099 | 8 PLATE | 1 | |
| 2038986 | 9 CIRCUIT BREAKER AS (70-AMPERE) | 1 | |
| 2038987 | 10 CIRCUIT BREAKER AS (40-AMPERE) | 2 | |
| 2038989 | 11 CIRCUIT BREAKER AS (20-AMPERE) | 3 | |
| 2072551 | 12 PLATE | 1 | |
| 2078271 | 13 SEAL | 1 | |
| 2204976 | 14 BAR-BUS | 1 | |
| 2395794 | 15 TIMER | 1 | |
| 2410244 | 16 WIRE AS | 1 | |
| 2427062 | 17 WIRE AS | 3 | |
| 2427064 | 18 WIRE AS | 1 | |
| 2427067 | 19 BRACKET AS | 1 | |
| 2427390 | 20 WIRE AS | 1 | |
| 2427391 | 21 BOX AS | 1 | |
| 3865172 | 22 WIRE AS | 1 | |
| 0625388 | 23 LOCKNUT (1-11-1/2-THD) | 2 | |
| 3E9865 | 25 LOCKNUT (1/4-20-THD) | 13 | |
| 3K8106 | 26 SCREW-MACHINE (8-32X1-IN) | 4 | |
| 3L7314 | 27 WASHER (0.406X0.62X0.032-IN THK) | 4 | |
| 4B1224 | 28 SCREW-MACHINE (8-32X1.5-IN) | 4 | |
| 4B4863 | 29 WASHER (4.7X11X1.2-MM THK) | 12 | |
| 4B5324 | 30 WASHER (3.9X9.6X1.2-MM THK) | 1 | |
| 4M5282 | 31 BOLT (1/4-20X1.5-IN) | 7 | |
| 5H6555 | 32 LOCKWASHER | 8 | |
| 5P7751 | 33 NUT-BRONZE (3/8-16-THD) | 4 | |
| 6D5801 | 34 LOCKNUT (8-32-THD) | 12 | |
| 7D6922 | 35 LOCKNUT (6-32-THD) | 9 | |
| 8T4205 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 7 | |
| 9S8750 | 37 NUT-FULL (1/4-20-THD) | 1 | |
| 9X6259 | 38 SCREW-MACHINE (6-32X0.375-IN) | 8 | |
| 4377386 | 39 FILM-IDENTIFICATION (CIRCUIT BREAKER) | 1 | |
| 5320674 | 40 BUSHING (CAPPED) | 2 |
