System And Components
Assembly
100%

579-8978 SENSOR & MTG GP-ELECTRICS/N NWH1-UP

Group No: 579-8978
Part NumberPart NameQty
0S05091 BOLT (3/8-16X0.75-IN)29
0S15872 BOLT (1/2-13X1.75-IN)1
0S16173 BOLT (5/16-18X0.75-IN)2
11232314 ADAPTER (1/2-14-THD)1
13257895 CLIP (LADDER)5
21475666 SEAL-O-RING2
21475687 SEAL-O-RING3
22871008 SEAL-O-RING3
23799609 CLIP (LADDER)1
256645310 SENSOR-TEMPERATURE (2-PIN)(ENGINE OIL)1
256645310A SENSOR-TEMPERATURE (2-PIN)(COOLANT)1
256645310B SENSOR-TEMPERATURE (2-PIN)(INTAKE MANIFOLD)1
261684711 ADAPTER18
522164113 SENSOR GP-SPEED (CRANKSHAFT)1
522164113A SENSOR GP-SPEED (CAMSHAFT)1
266013614 SENSOR GP-PRESSURE (THROTTLE)1
9X1813SLEEVE (8-CM)
9X3401PIN-CONNECTOR (16-GA TO 18-GA)3
2370228RECEPTACLE AS-CONNECTOR (3-PIN)1
274671815 SENSOR GP-PRESSURE (INTAKE MANIFOLD)1
318118116 SENSOR GP-SPEED (MAGNETIC)(FLYWHEEL)1
320306017 SENSOR GP-PRESSURE (ENGINE OIL FILTER INLET)1
320306017A SENSOR GP-PRESSURE (ENGINE COOLANT BLOCK INLET)1
320306318 SENSOR GP-PRESSURE (CRANKCASE)1
335399919 CONNECTOR2
352396421 CLIP (LADDER)28
353544123 ADAPTER-ELBOW1
592307224 SENSOR GP-TEMPERATURE (2-PIN)(THERMOCOUPLE, RH)8
592307224A SENSOR GP-TEMPERATURE (2-PIN)(TURBOCHARGER INLET, LH)1
592307224B SENSOR GP-TEMPERATURE (2-PIN)(TURBOCHARGER INLET, RH)1
592307224C SENSOR GP-TEMPERATURE (2-PIN)(THERMOCOUPLE, LH)8
416699925 SENSOR GP-PRESSURE (COOLANT INLET)1
416699925A SENSOR GP-PRESSURE (COOLANT OUTLET)1
4B428126 WASHER (16.8X33X2.5-MM THK)1
4P742827 CLIP (LADDER)3
4P742928 CLIP (LADDER)3
4P758129 CLIP (LADDER)2
4P813430 CLIP (LADDER)5
574868031 SENSOR GP-DETONATION (RH)4
574868031A SENSOR GP-DETONATION (LH)4
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)3
8T8731PLUG-CONNECTOR (3-PIN)1
9X1813SLEEVE (50-CM)
5M289432 WASHER-HARD (10.2X18.5X2.5-MM THK)29
5P824533 WASHER-HARD (13.5X25.5X3-MM THK)6
5P961734 ADAPTER1
6V656035 SEAL-O-RING2
6V660936 SEAL-O-RING1
7N281337 SPACER (13.8X25.4X23.8-MM THK)1
8L278638 SEAL-O-RING2
9M197439 WASHER-HARD (8.8X16X2-MM THK)2
9X677240 STRAP-CABLE47
524927441 ADAPTER2
