System And Components
255-5437 PANEL GP-ELECTRONIC -REMOTES/N G4A1-UP; G3N1-UP; G3R1-UP; G3T1-UP; G3X1-UP; G3Y1-UP; G3Z1-UP
Group No: 255-5437
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C6354 | 1 CAP-RECEPTACLE (ET CONNECTOR) | 2 | |
| 9X6772 | 2 STRAP-CABLE | 7 | |
| 1284249 | 3 LOCKWASHER | 1 | |
| 1328488 | 4 NUT-RING | 2 | |
| 1809214 | 5 NUT (1-11/16-18-THD) | 1 | |
| 3763101 | 6 GROMMET-BLIND | 3 | |
| 2490617 | 7 HARNESS AS-WIRING (DATA LINK) | 2 | |
| 2597024 | 8 HARNESS AS-WIRING (JACKET WATER HEATER) | 1 | |
| 9X8917 | 9 SCREW-MACHINE (4-40X9.52-MM) | 8 | |
| 2604826 | 10 PANEL GP-ELECTRONIC (DOOR) | 1 | |
| 2604827 | 11 PANEL GP-ELECTRONIC | 1 | |
| 2604828 | 12 TERMINAL & PLATE AS (COMMUNICATIONS) | 1 | |
| 2604829 | 13 TERMINAL & PLATE AS (AC) | 1 | |
| 2761253 | 14 HARNESS AS-PANEL (INTERFACE) | 1 | |
| 2761255 | 15 HARNESS AS-LIGHTING | 1 | |
| 2761256 | 16 HARNESS AS-WIRING (JUMPER) | 1 | |
| 1566175 | 17 CLIP (LADDER) | 3 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 14 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8C7581 | 20 SCREW-MACHINE (M4X0.7X8-MM) | 1 | |
| 1325789 | 21 CLIP (LADDER) | 1 | |
| 7K1181 | 22 STRAP-CABLE | 1 |
