System And Components
509-8326 SENSOR GP-LIQUID LEVEL -OILAN ATTACHMENT
Group No: 509-8326
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V5016 | 1 VALVE-BALL (OIL) | 1 | |
| 2147566 | 2 SEAL-O-RING | 3 | |
| 3696862 | 3 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 3603684 | PLUG | 1 | |
| 4186597 | 4 SWITCH GP-LIQUID LEVEL (OIL) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 4872127 | 5 MANIFOLD-OIL | 1 | |
| 5012086 | 6 HOSE AS | 1 | |
| 5012089 | 7 HOSE AS | 1 | |
| 5012090 | 8 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 0619593 | 9 ADAPTER | 1 | |
| 2287088 | 10 SEAL-O-RING | 1 | |
| 2287089 | 11 SEAL-O-RING | 2 | |
| 2674045 | 12 ELBOW | 1 | |
| 2M9780 | 13 SEAL-O-RING | 1 | |
| 4H1225 | 14 WASHER (11X22X6-MM THK) | 2 | |
| 4M5281 | 15 BOLT (1/4-20X0.75-IN) | 3 | |
| 5S7382 | 16 BOLT (3/8-16X1.375-IN) | 2 | |
| 6V9872 | 17 CONNECTOR | 1 | |
| 8C6870 | 18 CONNECTOR | 1 | |
| 8T4205 | 19 WASHER-HARD (7.2X14.5X2-MM THK) | 3 |
