289-2090 LINES GP-WATER -AFTERCOOLER

Group No: 289-2090

Part Number	Part Name	Qty
1N3872	1 SUPPORT	1
2W5225	2 FLANGE	2
3P6061	3 GASKET	1
4W0530	4 RING-RETAINING	2
4W0531	5 RETAINER	4
7C9597	6 FLANGE	2
7N6986	8 SUPPORT	1
1106995	9 PLATE	1
1109538	10 TUBE	1
5424631	11 BRACKET	1
1115056	12 CONNECTOR	1
1142040	13 ELBOW	1
1293083	14 ELBOW	1
1378219	15 ELBOW	1
1539481	16 CLAMP AS	4
1539963	17 RING	2
4947440	18 BRACKET	1
2617296	19 BRACKET AS	1
2680028	20 TUBE	1
2828537	21 HOUSING & REGULATOR GP	1
3457620	22 BRACKET	1
0L1351	23 BOLT (3/8-16X0.875-IN)	4
0L2070	24 BOLT (3/8-16X2.25-IN)	2
1653931	25 BOLT (3/8-16X1.75-IN)	4
1653929	26 BOLT (3/8-16X1.5-IN)	4
0S1594	27 BOLT (3/8-16X1-IN)	8
0T0055	28 BOLT (3/8-16X4.25-IN)	2
0T0065	29 BOLT (3/8-16X3.5-IN)	2
1932120	30 GROMMET	3
1A2029	31 BOLT (3/8-16X1.125-IN)	6
1A5822	32 BOLT (1/2-13X2.75-IN)	2
1C2251	33 BOLT (3/8-16X1.87-IN)	2
1F7958	34 NUT-FULL (1/2-13-THD)	8
2A4639	35 BOLT (3/8-16X1.625-IN)	1
2M0849	36 WASHER-HARD (13.5X25.5X5-MM THK)	1
3B1915	37 BOLT (3/8-16X1.375-IN)	1
3J1907	38 SEAL-O-RING	1
4F7387	39 SEAL-O-RING	1
5B0841	40 BOLT (5/8-18X1.75-IN)	4
5B2638	41 BOLT (3/8-16X5.25-IN)	2
5B4399	42 SEAL-O-RING	1
5M2894	43 WASHER-HARD (10.2X18.5X2.5-MM THK)	20
5P8245	44 WASHER-HARD (13.5X25.5X3-MM THK)	8
6H1717	45 BOLT (1/2-13X1.125-IN)	1
6J2680	46 SEAL-O-RING	4
6V1867	47 CLIP (SLOT)	3
6V1868	48 CLIP (TAB)	3
7W6492	49 PLUG-PIPE (1/2-14-THD)	1
8S9191	50 BOLT (3/8-16X4-IN)	2
8T1919	51 SEAL-O-RING	4
8T6767	52 PLUG-PIPE (3/8-18-THD)	1
8M9024	53 WASHER-HARD (10.2X22.5X5-MM THK)	4
7W9094	54 SPACER (11X20X9-MM THK)	1
9S4191	55 PLUG (9/16-18-THD)	1
9S8752	56 NUT-FULL (3/8-16-THD)	12
9X6458	57 WASHER-HARD (10.2X22.5X3-MM THK)	10
2B0947	58 BOLT (1/2-13X2.25-IN)	8
9Y6893	60 GASKET	2
