System And Components
104-5542 LINES GP-HYDRAULIC OIL COOLERS/N 5XC154-UP
Group No: 104-5542
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7R7941 | 1 CLAMP | 2 | |
| 7X0265 | 2 BOLT (1/4-20X2.75-IN) | 8 | |
| 8C1873 | 3 GAUGE (HYDRAULIC OIL PRESSURE) | 1 | |
| 7R8237 | 4 FILTER-OIL (HYDRAULIC) | 1 | |
| 8C2017 | 5 VALVE (CHECK) | 1 | |
| 8C1043 | 6 VALVE (THERMO) | 1 | |
| 0817000 | 7 COOLER-OIL | 1 | |
| 8T4025 | 8 GAUGE (AUX PRESSURE) | 1 | |
| 1G5377 | 9 FILTER GP-OIL (HYDRAULIC) | 1 | |
| 1322860 | INDICATOR | 1 | |
| 1G5459 | FILTER ELEMENT-OIL (STANDARD EFFICIENCY) | 1 | |
| 1278586 | SEAL-O-RING | 1 | |
| 5E4754 | 10 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR) | 1 | |
| 6R2678 | 11 CLAMP | 2 | |
| 0822766 | 12 MANIFOLD | 1 | |
| 7R7957 | 13 NUT | 22 | |
| 7R7908 | 14 CLAMP | 18 | |
| 7R7959 | 15 BOLT-SPECIAL (1/4-20X1.12-IN) | 16 | |
| 7R7954 | 16 PLATE | 8 | |
| 7V5628 | 17 PLATE (TOP) | 7 | |
| 4M5282 | 18 BOLT (1/4-20X1.5-IN) | 14 | |
| 7R7965 | 19 NUT | 4 | |
| 4V0611 | 20 CLAMP | 4 | |
| 4V0612 | 21 PLATE | 5 | |
| 7X0440 | 22 BOLT (5/16-18X1.75-IN) | 5 | |
| 7R8439 | 23 CLAMP | 6 | |
| 7R7964 | 24 PLATE | 1 | |
| 6W0210 | 25 BOLT (5/16-18X1.5-IN) | 1 | |
| 7R7907 | 26 CLAMP | 8 | |
| 7R7906 | 27 CLAMP | 4 | |
| 7R7962 | 28 CLAMP | 6 | |
| 7R8001 | 29 HOSE AS | 1 | |
| 3V0046 | 30 PLATE | 2 | |
| 8C6561 | 31 BOLT (5/16-18X1.375-IN) | 2 | |
| 6R2693 | 32 CLAMP-HALF | 6 | |
| 7R7952 | 33 COVER | 4 | |
| 1355955 | 34 VALVE GP-CONTROL | 2 | |
| 9B7237 | 35 BOLT (3/8-16X1.25-IN) | 8 | |
| 4B4278 | 36 WASHER (10.2X20.5X1.6-MM THK) | 27 | |
| 6V8801 | 37 NUT (3/8-16-THD) | 20 | |
| 8T2502 | 38 BOLT (3/8-16X1.125-IN) | 5 | |
| 4M5281 | 39 BOLT (1/4-20X0.75-IN) | 3 | |
| 8T4205 | 40 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 5P2566 | 41 BOLT (1/2-13X1.5-IN) | 4 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V9851 | 42 ELBOW | 1 | |
| 5S7379 | 43 BOLT (3/8-16X0.875-IN) | 4 | |
| 6V9830 | 44 CAP (ORFS) | 1 | |
| 4J5267 | 45 SEAL-O-RING | 1 | |
| 6V9746 | 46 SEAL-O-RING | 19 | |
| 6V9007 | 47 ELBOW | 2 | |
| 6V8398 | 48 SEAL-O-RING | 25 | |
| 3D2824 | 49 SEAL-O-RING | 14 | |
| 4J5477 | 50 SEAL-O-RING | 20 | |
| 6V8397 | 51 SEAL-O-RING | 38 | |
| 2M9780 | 52 SEAL-O-RING | 9 | |
| 3J1907 | 53 SEAL-O-RING | 8 | |
| 7X5308 | 54 CAP-DUST | 1 | |
| 5K9090 | 55 SEAL-O-RING | 6 | |
| 8T0315 | 56 SEAL-O-RING | 17 | |
| 3K0360 | 57 SEAL-O-RING | 1 | |
| 7J9108 | 58 SEAL-O-RING | 1 | |
| 4J0522 | 59 SEAL-O-RING | 1 | |
| 6V8400 | 60 SEAL-O-RING | 3 | |
| 2S4078 | 61 SEAL-O-RING | 3 | |
| 6V9006 | 62 ELBOW | 2 | |
| 5E7997 | 63 HOSE AS | 1 | |
| 5M2894 | 64 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 3B1915 | BOLT (3/8-16X1.375-IN) | 4 | |
| 1P4576 | FLANGE-HALF | 2 | |
| 1301807 | 65 PUMP GP-PISTON (PROPEL, AUXILIARY) | 1 | |
| 1C3860 | 66 FILTER-OIL (HYDRAULIC) | 1 | |
| 7R7988 | 67 HOSE AS | 1 | |
| 0314392 | 68 SEAL-O-RING | 1 | |
| 7R7989 | 69 HOSE AS | 1 | |
| 7R7992 | 70 HOSE AS | 1 | |
| 7R7993 | 71 HOSE AS | 2 | |
| 6V8715 | 72 CONNECTOR | 4 | |
| 7R7994 | 73 HOSE AS | 1 | |
| 6V8641 | 74 CONNECTOR | 3 | |
| 7X0873 | 75 TEE | 1 | |
| 7R7991 | 76 HOSE AS | 1 | |
| 6V8983 | 77 ELBOW | 1 | |
| 2P1293 | 78 LOCKNUT (1-3/16-12-THD) | 1 | |
| 0869673 | 79 HOSE AS | 1 | |
| 0869298 | 80 REDUCER | 3 | |
| 0869615 | 81 TEE | 2 | |
| 0869614 | 82 BULKHEAD | 2 | |
| 0871800 | 83 NUT | 2 | |
| 7R7591 | 84 HOSE AS | 1 | |
| 0869616 | 85 ADAPTER | 3 | |
| 0869619 | 86 TEE | 2 | |
| 9N7404 | 87 FITTING | 1 | |
| 0869617 | 88 ADAPTER | 6 | |
| 7R7592 | 89 HOSE AS | 1 | |
| 8T1492 | 90 ADAPTER | 3 | |
| 7R7593 | 91 HOSE AS | 1 | |
| 6V8637 | 92 CONNECTOR | 1 | |
| 7R7594 | 93 HOSE AS | 1 | |
| 7M8485 | 94 SEAL-O-RING | 1 | |
| 7R7595 | 95 HOSE AS | 1 | |
| 7R7596 | 96 HOSE AS | 1 | |
| 0868510 | 97 ADAPTER | 1 | |
| 1P4579 | 98 FLANGE-HALF | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T9389 | 99 BOLT (1/2-13X2.75-IN) | 4 | |
| 7R7597 | 100 HOSE AS | 1 | |
| 0823100 | 101 ADAPTER | 1 | |
| 7R7598 | 102 HOSE AS | 1 | |
| 7X0871 | 103 TEE | 3 | |
| 7R9572 | 104 ADAPTER | 2 | |
| 7R9003 | 105 HOSE AS | 1 | |
| 8T3611 | 106 CONNECTOR | 1 | |
| 0869672 | 107 HOSE AS | 1 | |
| 1P4578 | 108 FLANGE-HALF | 2 | |
| 0T0722 | BOLT | 4 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 8T6663 | 109 ADAPTER-PORT | 2 | |
| 0S1597 | 110 BOLT (1/4-28X1-IN) | 4 | |
| 6V8625 | 111 ELBOW | 1 | |
| 7R7987 | 112 HOSE AS | 1 | |
| 7X5300 | 113 ADAPTER GP | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8556 | NUT (1-3/16-12-THD) | 1 | |
| 6V8942 | REDUCER-O-RING | 1 | |
| 6V8734 | 114 UNION | 1 | |
| 6R2172 | 115 HOSE AS | 1 | |
| 6V5258 | 116 ADAPTER | 1 | |
| 7R7421 | 117 HOSE AS | 2 | |
| 5E8340 | 118 ELBOW | 2 | |
| 4J0524 | 119 SEAL-O-RING | 3 | |
| 7R7422 | 120 HOSE AS | 1 | |
| 6V9008 | 121 ELBOW (90-DEG) | 1 | |
| 7R8127 | 122 ADAPTER | 4 | |
| 5L2534 | 123 U-BOLT | 2 | |
| 8T4896 | 124 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 7X2459 | 125 ADAPTER-TEE | 2 | |
| 6V3965 | 126 FITTING (QUICK DISCONNECT) | 1 | |
| 7R7853 | 127 HOSE AS | 2 | |
| 5P1075 | 128 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 8T9101 | 129 BOLT (3/8-16X2.75-IN) | 6 | |
| 6V8628 | 130 ELBOW | 2 | |
| 7R7846 | 131 HOSE AS | 2 | |
| 7R7847 | 132 HOSE AS | 1 | |
| 7R7845 | 133 HOSE AS | 1 | |
| 6V9001 | 134 ELBOW | 1 | |
| 6V9843 | 135 TEE | 1 | |
| 7R7848 | 136 HOSE AS | 1 | |
| 3J7354 | 137 SEAL-O-RING | 3 | |
| 7R7990 | 138 HOSE AS | 2 | |
| 6V9837 | 139 TEE-SWIVEL | 4 | |
| 6V8633 | 140 CONNECTOR | 4 | |
| 6V9839 | 141 TEE-SWIVEL | 2 | |
| 6V8556 | 142 NUT (1-3/16-12-THD) | 2 | |
| 6V8941 | 143 REDUCER | 2 | |
| 6V9836 | 144 TEE-SWIVEL | 4 | |
| 7R7892 | 145 HOSE AS | 2 | |
| 7R7999 | 146 HOSE AS | 1 | |
| 7R7589 | 147 HOSE AS | 1 | |
| 8T8902 | 148 ADAPTER-TEE | 1 | |
| 6V8627 | 149 ELBOW | 2 | |
| 0869671 | 150 HOSE AS | 1 | |
| 7R6774 | 151 ADAPTER | 1 | |
| 8S7169 | 152 COUPLING | 2 | |
| 2T2305 | 153 ELBOW | 1 | |
| 7R7251 | 154 TUBE AS | 1 | |
| 0870330 | 155 HOSE AS | 1 | |
| 7R7599 | 156 HOSE AS | 1 | |
| 8C6866 | 157 CONNECTOR | 1 | |
| 6V9000 | 158 ELBOW | 1 | |
| 0869624 | 159 HOSE AS | 1 | |
| 1G7951 | 161 HOSE AS | 1 | |
| 7R7849 | 162 HOSE AS | 1 | |
| 6V9844 | 163 TEE-SWIVEL | 1 |
