System And Components
524-3160 PUMP GP-AUXILIARY SEA WATERS/N SSW1-UP
Group No: 524-3160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3N8468 | 1 CLAMP AS | 2 | |
| 1939120 | 2 BODY | 1 | |
| 1939207 | 3 RING | 1 | |
| 2765432 | 4 BOOT | 1 | |
| 2767333 | 5 VALVE-BALL | 1 | |
| 2779758 | 6 BALL BEARING | 1 | |
| 2779759 | 7 BEARING | 1 | |
| 2779760 | 8 SEAL-LIP TYPE | 2 | |
| 2779782 | 9 PLUG-PIPE | 1 | |
| 4451693 | 10 SEAL AS-WATER PUMP | 2 | |
| 3990319 | 11 PLUG-CUP | 1 | |
| 3972685 | 12 IMPELLER | 1 | |
| 3972687 | 13 IMPELLER | 1 | |
| 5243154 | 14 SHAFT-PUMP | 1 | |
| 3972689 | 15 PLATE-PORT | 1 | |
| 3972690 | 16 PLATE-PORT | 1 | |
| 4221831 | 17 BODY | 1 | |
| 5243157 | 18 BODY | 1 | |
| 4221833 | 19 HOUSING-BEARING | 1 | |
| 2263571 | 20 SEAL-O-RING | 1 | |
| 3990338 | 21 MANIFOLD | 1 | |
| 1218117 | 22 SEAL-O-RING | 1 | |
| 1310074 | 23 SEAL-O-RING | 1 | |
| 1313295 | 24 RING-RETAINING | 1 | |
| 1505311 | 25 LOCKWASHER | 4 | |
| 1562603 | 26 BOLT (M8X1.25X25-MM) | 10 | |
| 1683349 | 27 PLUG-PIPE | 1 | |
| 1953443 | 28 SEAL-O-RING | 1 | |
| 2054832 | 29 SEAL-O-RING | 2 | |
| 2S4078 | 30 SEAL-O-RING | 1 | |
| 4M0034 | 31 RING-RETAINING | 1 | |
| 7F7259 | 32 LOCKWASHER | 10 | |
| 8T4192 | 33 BOLT (M12X1.75X25-MM) | 4 | |
| 1003061 | 34 SHIM (0.127-MM THK) | 1 | |
| 1003062 | 35 SHIM (0.254-MM THK) | 1 | |
| 1003063 | 36 SHIM (0.305-MM THK) | 1 | |
| 1003064 | 37 SHIM (0.381-MM THK) | 1 |
