System And Components
489-3101 LINES GP-HYDRAULICS/N MLX1-UP
Group No: 489-3101
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5R7326 | 1 BUSHING-REDUCER | 2 | |
| 5V9221 | 2 SPACER (13.8X25X25-MM THK) | 1 | |
| 6V8251 | 3 TEE-PIPE | 3 | |
| 6W7451 | 4 VALVE (MANUAL BALL) | 1 | |
| 0058615 | 5 NIPPLE-PIPE | 1 | |
| 0374685 | 6 ELBOW | 1 | |
| 1363596 | 7 VALVE-REGULATOR | 1 | |
| 1415147 | 8 ADAPTER | 1 | |
| 1598091 | 9 BRACKET | 1 | |
| 2015551 | 10 ADAPTER | 3 | |
| 2965728 | 11 CONNECTOR-PIPE | 3 | |
| 2977947 | 12 ADAPTER | 2 | |
| 3136326 | 13 VALVE-REGULATOR | 1 | |
| 3704696 | 14 VALVE AS-CHECK | 1 | |
| 3874391 | 15 ADAPTER-CROSS | 1 | |
| 3906899 | 16 FILTER AS (HYDRAULIC) | 1 | |
| 3918878 | FILTER ELEMENT-OIL | 1 | |
| 3941462 | 17 BRACKET | 1 | |
| 3987525 | 18 SPACER (13.88X21.34X139-MM THK) | 4 | |
| 4205605 | 19 HOSE AS | 1 | |
| 4205606 | 20 HOSE AS | 1 | |
| 4205608 | 21 HOSE AS | 1 | |
| 4205609 | 22 HOSE AS | 1 | |
| 4205610 | 23 HOSE AS | 1 | |
| 4205611 | 24 HOSE AS | 1 | |
| 4205612 | 25 HOSE AS | 1 | |
| 4205613 | 26 HOSE AS | 1 | |
| 4205618 | 27 TUBE AS | 1 | |
| 4205658 | 28 HOSE AS | 1 | |
| 4205659 | 29 TUBE AS | 1 | |
| 4590662 | 30 ADAPTER | 1 | |
| 4723196 | 31 VALVE-THERMAL COMPENSATOR | 1 | |
| 4893094 | 32 HOSE AS | 1 | |
| 4893095 | 33 TUBE AS | 1 | |
| 4893096 | 34 TUBE AS | 1 | |
| 4893097 | 35 TUBE AS | 1 | |
| 4893098 | 36 TUBE AS | 1 | |
| 4893099 | 37 TUBE AS | 1 | |
| 4893100 | 38 BRACKET AS | 1 | |
| 0057541 | 39 ELBOW-PIPE | 2 | |
| 1093657 | 40 CONNECTOR | 1 | |
| 1129252 | 41 SPACER (13X25X22.14-MM THK) | 1 | |
| 1319367 | 42 BUSHING-REDUCER | 2 | |
| 1745811 | 43 ELBOW | 1 | |
| 1B2718 | 44 BOLT (1/4-20X6-IN) | 6 | |
| 1F3605 | 45 BUSHING-REDUCER | 2 | |
| 1K6872 | 46 LOCKNUT (1/2-13-THD) | 7 | |
| 1P4578 | 47 FLANGE-HALF | 2 | |
| 2006345 | 48 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 49 STRAP-CABLE | 2 | |
| 2124991 | 50 ADAPTER-TEE | 1 | |
| 2291444 | 51 ELBOW | 1 | |
| 2D6235 | 52 LOCKNUT (1/4-20-THD) | 18 | |
| 2K4973 | 53 LOCKNUT (3/8-16-THD) | 4 | |
| 2M9780 | 54 SEAL-O-RING | 1 | |
| 2S4078 | 55 SEAL-O-RING | 2 | |
| 2T1922 | 56 ELBOW | 2 | |
| 3J5389 | 57 PLUG (EXTERNAL) | 1 | |
| 3J7354 | 58 SEAL-O-RING | 1 | |
| 4J0522 | 59 SEAL-O-RING | 1 | |
| 4J5477 | 60 SEAL-O-RING | 1 | |
| 5B7666 | 61 ELBOW | 1 | |
| 5C6565 | 62 BOLT (1/2-13X1.125-IN) | 4 | |
| 5K9090 | 63 SEAL-O-RING | 2 | |
| 5P2424 | 64 BOLT (1/2-13X2.25-IN) | 1 | |
| 5P4481 | 65 ADAPTER-O-RING | 1 | |
| 5P7470 | 66 CLIP (SLOT) | 3 | |
| 5P7471 | 67 CLIP (TAB) | 3 | |
| 5P7703 | 68 GROMMET (52-MM ID) | 1 | |
| 5P8182 | 69 GROMMET (46-MM ID) | 2 | |
| 5V6152 | 70 CLAMP | 30 | |
| 6K6307 | 71 SEAL-O-RING | 5 | |
| 6V4516 | 72 ADAPTER | 2 | |
| 6V5729 | 73 LOCKNUT (7/16-14-THD) | 1 | |
| 6V8398 | 74 SEAL-O-RING | 4 | |
| 6V8400 | 75 SEAL-O-RING | 15 | |
| 6V9006 | 76 ELBOW | 1 | |
| 6V9855 | 77 ELBOW | 2 | |
| 7R7951 | 78 PLATE | 32 | |
| 7X0265 | 79 BOLT (1/4-20X2.75-IN) | 4 | |
| 7X0267 | 80 BOLT (1/4-20X3.25-IN) | 4 | |
| 7X0271 | 81 BOLT (1/4-20X5.5-IN) | 2 | |
| 7X0312 | 82 BOLT (7/16-14X2.5-IN) | 1 | |
| 7X3391 | 83 WASHER-HARD (13.5X32X6-MM THK) | 4 | |
| 7X5331 | 84 ELBOW | 1 | |
| 8C3793 | 85 BOLT (1/4-20X3.75-IN) | 6 | |
| 8C3991 | 86 ADAPTER | 1 | |
| 8C6872 | 87 CONNECTOR | 2 | |
| 8C6875 | 88 CONNECTOR | 2 | |
| 8T0315 | 89 SEAL-O-RING | 11 | |
| 8T1682 | 90 ELBOW | 1 | |
| 8T4205 | 91 WASHER-HARD (7.2X14.5X2-MM THK) | 40 | |
| 8T4223 | 92 WASHER-HARD (13.5X25.5X3-MM THK) | 15 | |
| 8T4896 | 93 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T5360 | 94 WASHER (12X22.5X2.5-MM THK) | 6 | |
| 8T6756 | 95 ELBOW | 1 | |
| 8T7926 | 96 CONNECTOR | 1 | |
| 8T8916 | 97 BOLT (7/16-14X1.5-IN) | 4 | |
| 8T8919 | 98 BOLT (1/2-13X1.75-IN) | 3 | |
| 8T9377 | 99 BOLT (3/8-16X2.25-IN) | 4 | |
| 8T9392 | 100 BOLT (1/2-13X7.5-IN) | 4 |
