System And Components
510-0840 LINES GP-TURBOCHARGER OILS/N MD5202-UP
Group No: 510-0840
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2528374 | 1 GASKET | 2 | |
| 4501698 | 2 ADAPTER AS | 1 | |
| 6V9350 | TEE-BULKHEAD | 1 | |
| 2287091 | SEAL-O-RING | 3 | |
| 4570780 | 3 FLANGE | 2 | |
| 5185007 | 4 TUBE AS | 1 | |
| 5080079 | 5 TUBE AS | 1 | |
| 5100826 | 6 TUBE AS | 1 | |
| 5100827 | 7 BRACKET | 1 | |
| 5100837 | 8 TUBE AS | 1 | |
| 5100838 | 9 TUBE AS | 1 | |
| 0L1143 | 10 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 2 | |
| 1252784 | 12 ELBOW | 2 | |
| 1A2029 | 13 BOLT (3/8-16X1.125-IN) | 2 | |
| 2815975 | 14 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3218632 | 16 CONNECTOR AS | 2 | |
| 6V8632 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3537954 | 17 GROMMET | 1 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN) | 1 | |
| 4L8149 | 19 GASKET | 2 | |
| 5A3604 | 20 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 4 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 6K4934 | 22 CLIP (SLOT) | 2 | |
| 6K4935 | 23 CLIP (TAB) | 2 | |
| 6V5134 | 24 SEAL-O-RING | 4 | |
| 6V6758 | 25 CLIP (2-PIECE) | 2 | |
| 6V6759 | 26 CLIP (2-PIECE) | 2 | |
| 6V9170 | 27 NUT-BULKHEAD (1-14-THD) | 1 | |
| 8T1889 | 28 CLIP (SLOT) | 1 | |
| 8T1890 | 29 CLIP (TAB) | 1 | |
| 9G8140 | 30 SPACER (10.5X25X15-MM THK) | 1 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 32 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 7X0872 | 33 TEE-SWIVEL | 1 | |
| 2287091 | 34 SEAL-O-RING | 1 | |
| 2443712 | 35 PLUG AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 |
