System And Components
536-5092 SHIELD GP-EXHAUST -THERMAL PROTECTION (CHG -00)AN ATTACHMENT
Group No: 536-5092
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4774546 | 1 SHIELD GP-EXHAUST | 1 | |
| 4776761 | 2 BOLT-FLANGE HEAD (3/8-16X0.625-IN) | 30 | |
| 4953852 | 3 SHIELD AS-EXHAUST | 1 | |
| 4953853 | 4 SHIELD AS-EXHAUST | 1 | |
| 4953854 | 5 SHIELD AS-EXHAUST | 1 | |
| 4953855 | 6 SHIELD AS-EXHAUST | 1 | |
| 4953856 | 7 SHIELD | 1 | |
| 4953857 | 8 SHIELD | 1 | |
| 4953858 | 9 SHIELD | 1 | |
| 4953859 | 10 SHIELD | 2 | |
| 4953860 | 11 SHIELD | 1 | |
| 4953862 | 12 SHIELD | 1 | |
| 4953863 | 13 SHIELD | 1 | |
| 4953869 | 14 SHIELD | 1 | |
| 4953870 | 15 SHIELD | 1 | |
| 5099378 | 16 BRACKET AS | 1 | |
| 5099379 | 17 BRACKET AS | 1 | |
| 5099380 | 18 BRACKET AS | 1 | |
| 5099381 | 19 BRACKET AS | 1 | |
| 5099382 | 20 BRACKET AS | 10 | |
| 5099383 | 21 SHIELD AS-EXHAUST | 1 | |
| 5099384 | 22 SHIELD AS-EXHAUST | 1 | |
| 5099385 | 23 SHIELD AS-TURBOCHARGER | 1 | |
| 5099386 | 24 SHIELD AS-TURBOCHARGER | 1 | |
| 5099388 | 25 SHIELD AS-TURBOCHARGER | 4 | |
| 5099389 | 26 BRACKET AS | 1 | |
| 5099390 | 27 BRACKET AS | 1 | |
| 5099391 | 28 BRACKET AS | 2 | |
| 5099392 | 29 SHIELD AS-TURBOCHARGER | 2 | |
| 5099393 | 30 SHIELD AS-TURBOCHARGER | 2 | |
| 5099394 | 31 SHIELD AS-TURBOCHARGER | 1 | |
| 5116730 | 32 SHIELD AS-TURBOCHARGER | 1 | |
| 5116731 | 33 SHIELD AS-TURBOCHARGER | 1 | |
| 4L6454 | 34 BOLT (3/8-16X1-IN) | 25 | |
| 5P1075 | 35 WASHER-HARD (10.2X22.5X3-MM THK) | 46 | |
| 5P1076 | 36 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6V8801 | 37 NUT (3/8-16-THD) | 36 | |
| 7X0772 | 38 WASHER-HARD (10.2X25.5X2.5-MM THK) | 15 | |
| 8T4192 | 39 BOLT (M12X1.75X25-MM) | 4 |
