System And Components
393-5643 REGULATOR GP-TEMPERATURE -AFTERCOOLERS/N PPE1-UP
Group No: 393-5643
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 2W5225 | 2 FLANGE | 2 | |
| 3P6061 | 3 GASKET | 1 | |
| 4W0530 | 4 RING-RETAINING | 4 | |
| 4W0531 | 5 RETAINER | 8 | |
| 7C9597 | 6 FLANGE | 2 | |
| 9S9635 | 7 JOINT AS-TUBE | 1 | |
| 9X7523 | SEAL | 2 | |
| 1106995 | 8 PLATE | 1 | |
| 1109538 | 9 TUBE | 1 | |
| 1115052 | 10 BRACKET | 1 | |
| 1115056 | 11 CONNECTOR | 1 | |
| 1142040 | 12 ELBOW | 1 | |
| 1293083 | 13 ELBOW | 1 | |
| 1965052 | 14 CLIP (SLOT) | 4 | |
| 1965053 | 15 CLIP (TAB) | 4 | |
| 2140731 | 16 BRACKET | 1 | |
| 4594911 | 17 VALVE GP-THERMOSTATIC (AFTERCOOLER) | 1 | |
| 2301072 | 18 GASKET | 1 | |
| 3795142 | 19 BRACKET | 1 | |
| 3863398 | 20 BRACKET | 1 | |
| 3935644 | 21 TUBE | 1 | |
| 3935645 | 22 TUBE | 1 | |
| 0303978 | 23 CONNECTOR | 1 | |
| 0L1351 | 24 BOLT (3/8-16X0.875-IN) | 8 | |
| 0L2070 | 25 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1585 | 26 BOLT (1/2-13X1.5-IN) | 1 | |
| 0S1590 | 27 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 28 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 29 BOLT (3/8-16X1-IN) | 8 | |
| 0T0065 | 30 BOLT (3/8-16X3.5-IN) | 2 | |
| 1874606 | 31 HOSE AS | 1 | |
| 1A2029 | 32 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 33 BOLT (1/2-13X2.75-IN) | 2 | |
| 1C2251 | 34 BOLT (3/8-16X1.87-IN) | 2 | |
| 1F7958 | 35 NUT-FULL (1/2-13-THD) | 10 | |
| 2M0849 | 36 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 2V4387 | 37 SPACER (10.312X25.4X23.11-MM THK) | 1 | |
| 3B1915 | 38 BOLT (3/8-16X1.375-IN) | 1 | |
| 3J7354 | 39 SEAL-O-RING | 2 | |
| 3V3308 | 40 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 4F7387 | 41 SEAL-O-RING | 1 | |
| 5B0841 | 42 BOLT (5/8-18X1.75-IN) | 4 | |
| 5B2638 | 43 BOLT (3/8-16X5.25-IN) | 2 | |
| 5B4399 | 44 SEAL-O-RING | 1 | |
| 5M2894 | 45 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P2645 | 46 ELBOW | 1 | |
| 5P8245 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 6H1717 | 48 BOLT (1/2-13X1.125-IN) | 1 | |
| 6H6698 | 49 COVER | 1 | |
| 6J2680 | 50 SEAL-O-RING | 3 | |
| 7D1649 | 51 WASHER-HARD (13.5X32X5-MM THK) | 5 | |
| 7W6492 | 52 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8T1919 | 53 SEAL-O-RING | 4 | |
| 9S8752 | 54 NUT-FULL (3/8-16-THD) | 7 | |
| 9X6458 | 55 WASHER-HARD (10.2X22.5X3-MM THK) | 15 | |
| 2B0947 | 56 BOLT (1/2-13X2.25-IN) | 10 | |
| 9Y6893 | 57 GASKET | 2 |
