System And Components
352-0924 LINES GP-WATER -UPPERS/N NWG1-UP
Group No: 352-0924
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W0530 | 1 RING-RETAINING | 2 | |
| 4W0531 | 2 RETAINER | 4 | |
| 7N3368 | 3 GASKET | 2 | |
| 8N0386 | 4 FLANGE | 1 | |
| 8N1989 | 5 TUBE | 1 | |
| 9Y6892 | 6 ELBOW-OIL COOLER | 1 | |
| 9Y6893 | 7 GASKET | 1 | |
| 2006436 | 8 ELBOW | 1 | |
| 2037069 | 9 ELBOW | 1 | |
| 2037072 | 10 ELBOW | 1 | |
| 2106279 | 11 TUBE | 1 | |
| 2154794 | 12 ELBOW | 2 | |
| 2525612 | 13 TUBE | 1 | |
| 0L1351 | 14 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S1587 | 15 BOLT (1/2-13X1.75-IN) | 8 | |
| 0S1588 | 16 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 8 | |
| 0T0055 | 18 BOLT (3/8-16X4.25-IN) | 2 | |
| 1A1460 | 19 BOLT (1/2-13X2-IN) | 4 | |
| 1A5183 | 20 BOLT (3/8-16X4.75-IN) | 5 | |
| 1A5964 | 21 BOLT (3/8-16X4.5-IN) | 1 | |
| 1F7958 | 22 NUT-FULL (1/2-13-THD) | 4 | |
| 4N1320 | 24 GASKET (ADAPTER) | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 6V1454 | 27 SEAL-O-RING | 2 | |
| 6V1581 | 28 CLIP (SLOT) | 1 | |
| 6V1582 | 29 CLIP (TAB) | 1 | |
| 6V5066 | 30 SEAL-O-RING | 1 | |
| 8T1919 | 31 SEAL-O-RING | 4 | |
| 8T6766 | 32 PLUG-PIPE | 2 | |
| 9S8752 | 33 NUT-FULL (3/8-16-THD) | 5 | |
| 3179526 | 34 BRACKET | 1 | |
| 1539481 | 35 CLAMP AS | 4 | |
| 1539963 | 36 RING | 2 | |
| 1653931 | 37 BOLT (3/8-16X1.75-IN) | 8 | |
| 4468432 | 38 SEAL-O-RING | 2 | |
| 9X6458 | 39 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
