System And Components
448-4296 AIR CLEANER GPS/N TZK1-UP; FLX1-UP
Group No: 448-4296
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P3860 | 1 CLAMP-HOSE | 6 | |
| 6N2677 | 2 HOSE-REDUCER | 2 | |
| 0120703 | 3 CONNECTOR | 2 | |
| 1505030 | 4 INDICATOR-AIR FILTER CHANGE | 2 | |
| 1622177 | 5 HOSE | 2 | |
| 4350403 | 6 TUBE AS | 1 | |
| 4350405 | 7 TUBE-AIR | 1 | |
| 4375087 | 8 BRACKET | 2 | |
| 4436196 | 9 VALVE GP-DUST | 2 | |
| 1S5485 | VALVE-DUST | 1 | |
| 4436197 | 10 AIR CLEANER GP | 2 | |
| 4484298 | 11 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4484299 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4484303 | 13 PLATE | 2 | |
| 4484304 | 14 PLATE | 2 | |
| 4M6425 | 15 BOLT (5/16-18X1-IN) | 10 | |
| 5P1075 | 16 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P4116 | 17 WASHER-HARD (8.8X20.5X2-MM THK) | 18 | |
| 5P4869 | 18 CLAMP-HOSE | 2 | |
| 6V8801 | 19 NUT (3/8-16-THD) | 2 | |
| 7X7729 | 20 WASHER (11X25X3-MM THK) | 8 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4908 | 22 BOLT (M8X1.25X25-MM) | 8 | |
| 9B7237 | 23 BOLT (3/8-16X1.25-IN) | 2 |
