System And Components
382-7832 LINES GP-WATER -LOWERS/N E6T1-UP
Group No: 382-7832
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B4971 | 1 SPACER (0.406X1X1-IN THK) | 4 | |
| 3P6061 | 2 GASKET | 1 | |
| 4W0530 | 3 RING-RETAINING | 4 | |
| 4W0531 | 4 RETAINER | 8 | |
| 6V1581 | 5 CLIP (SLOT) | 6 | |
| 6V1582 | 6 CLIP (TAB) | 6 | |
| 7N6986 | 7 SUPPORT | 2 | |
| 9S9635 | 8 JOINT AS-TUBE | 2 | |
| 9X7523 | SEAL | 2 | |
| 9Y6892 | 9 ELBOW-OIL COOLER | 1 | |
| 9Y6893 | 10 GASKET | 1 | |
| 9Y8263 | 11 ELBOW | 1 | |
| 1424280 | 12 HOUSING | 1 | |
| 1539963 | 13 RING | 4 | |
| 1571435 | 14 CLAMP | 8 | |
| 1571437 | 15 BRACKET | 8 | |
| 1882929 | 16 TUBE AS | 1 | |
| 1882930 | 17 TUBE AS | 1 | |
| 1978127 | 18 TUBE AS | 1 | |
| 1978426 | 19 TUBE | 1 | |
| 2006978 | 20 TUBE AS | 1 | |
| 2006979 | 21 TUBE | 1 | |
| 0L1143 | 22 BOLT (3/8-16X2.5-IN) | 2 | |
| 0S1590 | 23 BOLT (3/8-16X2-IN) | 2 | |
| 1653929 | 24 BOLT (3/8-16X1.5-IN) | 3 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 30 | |
| 0T0055 | 26 BOLT (3/8-16X4.25-IN) | 6 | |
| 1A1460 | 27 BOLT (1/2-13X2-IN) | 4 | |
| 1A2029 | 28 BOLT (3/8-16X1.125-IN) | 2 | |
| 1F7958 | 29 NUT-FULL (1/2-13-THD) | 4 | |
| 2B0858 | 30 PLUG-PIPE | 1 | |
| 3P0815 | 31 SEAL-O-RING | 1 | |
| 5M2894 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 40 | |
| 5M6213 | 33 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P8245 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 1653925 | 35 BOLT (3/8-16X5.75-IN) | 2 | |
| 7X0575 | 36 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 8T1919 | 37 SEAL-O-RING | 7 | |
| 8T6762 | 38 PLUG-PIPE (1/2-14-THD) | 4 | |
| 9L9132 | 39 WASHER-HARD (10.2X25.5X2.5-MM THK) | 4 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 15 | |
| 9X6458 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 8 |
