System And Components
455-7156 LINES GP-JACKET WATER HEATERAN ATTACHMENT
Group No: 455-7156
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0065707 | 1 ELBOW-PIPE | 1 | |
| 1969420 | 2 VALVE-BALL | 2 | |
| 3089535 | 3 HOSE AS | 1 | |
| 3754809 | 4 TUBE AS | 1 | |
| 3754810 | 5 PLATE | 2 | |
| 3754811 | 6 HOSE AS | 1 | |
| 3754812 | 7 HOSE AS | 1 | |
| 3772874 | 8 BRACKET AS | 1 | |
| 8J6030 | NUT-WELD (3/8-16-THD) | 2 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 4 | |
| 0T0319 | 11 BOLT (7/16-14X2-IN) | 2 | |
| 1189901 | 12 SPACER (12X20X10-MM THK) | 2 | |
| 1314863 | 13 ELBOW | 1 | |
| 1984777 | 14 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 1984778 | 15 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 1F7958 | 16 NUT-FULL (1/2-13-THD) | 2 | |
| 1L0254 | 17 ELBOW | 1 | |
| 2627273 | 18 WASHER-HARD (31X52.5X22.6-MM THK) | 4 | |
| 2H3745 | 19 BOLT (1-14X2.75-IN) | 4 | |
| 2S2053 | 20 CLIP (LOOP) | 1 | |
| 3B7280 | 21 NIPPLE-PIPE | 1 | |
| 3S1546 | 22 NUT-FULL (7/16-14-THD) | 2 | |
| 5K9090 | 23 SEAL-O-RING | 6 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 5P7464 | 25 CLIP (SLOT) | 4 | |
| 5P7465 | 26 CLIP (TAB) | 4 | |
| 5P8244 | 27 WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 6V7359 | 28 GROMMET (25-MM ID, 37-MM OD) | 4 | |
| 6V8734 | 29 UNION | 2 | |
| 8C6875 | 30 CONNECTOR | 1 | |
| 9S1366 | 31 BOLT (1/2-13X2.5-IN) | 2 |
