System And Components
166-8039 FILTER GP-ENGINE OILS/N 3KD166-UP
Group No: 166-8039
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3333 | 1 TUBE | 1 | |
| 1P1367 | 2 PLUNGER (RELIEF VALVE) | 3 | |
| 1S7106 | 3 COVER | 3 | |
| 1W8129 | 4 SUPPORT | 2 | |
| 2W1053 | 5 PLUG | 1 | |
| 2W1055 | 6 ELBOW | 1 | |
| 2W1635 | 7 SPRING | 1 | |
| 2W1969 | 8 VALVE-BYPASS (OIL COOLER)(OIL COOLER) | 1 | |
| 2W7226 | 9 ADAPTER | 1 | |
| 4B3140 | 10 COVER | 1 | |
| 4W5596 | 11 COVER | 1 | |
| 4W5597 | 12 COVER | 1 | |
| 6B0933 | 13 SPACER (10.31X19.05X6.35-MM THK) | 4 | |
| 6B9202 | 14 SPRING | 2 | |
| 7C9217 | 15 ELBOW (OIL COOLER BYPASS) | 1 | |
| 7G6713 | 16 SPRING-MAIN | 3 | |
| 7N5413 | 17 ELBOW | 1 | |
| 7N5416 | 18 ELBOW (OUTLET) | 1 | |
| 7N7697 | 19 PLUNGER AS | 2 | |
| 7M1808 | DOWEL | 1 | |
| 8N1991 | 20 RING-RETAINING | 2 | |
| 8N1992 | 21 RETAINER | 4 | |
| 8N2001 | 22 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 8N2929 | 23 COVER | 2 | |
| 9Y8387 | 24 GASKET | 3 | |
| 9Y8388 | 25 GASKET | 3 | |
| 1008075 | 26 CLAMP AS | 2 | |
| 1113820 | 27 RING-RETAINING | 2 | |
| 1116119 | 28 SHIELD | 3 | |
| 1215734 | 29 ADAPTER-BASE | 1 | |
| 1335915 | 30 ELBOW | 1 | |
| 1519270 | 31 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 2 | |
| 1667679 | 32 SUPPORT | 1 | |
| 1680278 | 33 TUBE AS | 1 | |
| 1680279 | 34 TUBE AS | 1 | |
| 1732943 | 35 BRACKET | 1 | |
| 2640450 | 36 CLAMP AS | 2 | |
| 2752604 | 37 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 3 | |
| 0619456 | 38 SEAL-O-RING | 4 | |
| 0L1143 | 39 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1571 | 40 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1588 | 41 BOLT (3/8-16X1.25-IN) | 20 | |
| 0S1591 | 42 BOLT (3/8-16X1.5-IN) | 34 | |
| 0S1594 | 43 BOLT (3/8-16X1-IN) | 14 | |
| 0T0055 | 44 BOLT (3/8-16X4.25-IN) | 4 | |
| 1092332 | 45 SEAL-O-RING | 6 | |
| 1A2029 | 46 BOLT (3/8-16X1.125-IN) | 5 | |
| 1A5964 | 47 BOLT (3/8-16X4.5-IN) | 4 | |
| 2B2695 | 48 BOLT (5/16-18X0.875-IN) | 6 | |
| 3P0655 | 49 SEAL-O-RING | 3 | |
| 5F4899 | 50 BOLT (3/8-16X5.5-IN) | 1 | |
| 5M2894 | 51 WASHER-HARD (10.2X18.5X2.5-MM THK) | 37 | |
| 5P4892 | 52 SEAL-O-RING | 1 | |
| 5P5846 | 53 SEAL-O-RING | 1 | |
| 5P7817 | 54 SEAL-O-RING | 1 | |
| 6V0267 | 55 CLIP (TAB) | 1 | |
| 6V0268 | 56 CLIP (SLOT) | 1 | |
| 6V3908 | 57 SEAL-O-RING | 1 | |
| 6V4589 | 58 SEAL-O-RING | 2 | |
| 6V5048 | 59 SEAL-O-RING | 2 | |
| 7F9090 | 60 SCREW-DRIVE (NO 8X3/8-IN) | 6 | |
| 8T6758 | 61 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8T6762 | 62 PLUG-PIPE (1/2-14-THD) | 3 | |
| 8T6765 | 63 PLUG-PIPE (1/4-18-THD)(1/4-18-THD) | 1 | |
| 9M1974 | 64 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9S4182 | 65 PLUG (7/16-20-THD) | 2 | |
| 9S4190 | 66 PLUG-O-RING (7/8-14-THD) | 2 | |
| 9S8752 | 67 NUT-FULL (3/8-16-THD) | 20 | |
| 9X6458 | 68 WASHER-HARD (10.2X22.5X3-MM THK) | 10 |
