System And Components
380-6910 LINES GP-TURBOCHARGER OILPART OF 523-2192, 553-0266, 553-0267, 553-0268, 553-0269, 553-0270 ENGINE AR-COMPLETE
Group No: 380-6910
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W0752 | 1 GASKET | 4 | |
| 4P0692 | 2 CLAMP AS | 20 | |
| 1081434 | GROMMET | 1 | |
| 6I0804 | 3 ADAPTER-TURBOCHARGER OIL | 2 | |
| 6I0805 | 4 ADAPTER-TURBOCHARGER OIL | 2 | |
| 4830398 | 5 TUBE AS (OIL) | 2 | |
| 7E5330 | 6 BRACKET | 6 | |
| 7N5094 | 7 ELBOW-DRAIN | 4 | |
| 7N7559 | 8 GASKET | 4 | |
| 9Y5814 | 9 ELBOW-DRAIN | 4 | |
| 4830333 | 10 HOSE AS | 4 | |
| 2501496 | 11 ELBOW | 2 | |
| 4830467 | 12 TUBE AS (OIL) | 1 | |
| 4935021 | 13 TUBE AS (WATER) | 1 | |
| 2673393 | 14 BRACKET | 4 | |
| 4674097 | 15 TUBE AS | 1 | |
| 4504986 | 16 TUBE AS-OIL | 1 | |
| 4504985 | 17 TUBE AS-OIL | 2 | |
| 0038581 | 18 TEE-UNION | 2 | |
| 4875252 | 19 BRACKET | 2 | |
| 4510404 | 20 ADAPTER AS | 1 | |
| 0314136 | TEE-FLARED | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 0L1143 | 21 BOLT (3/8-16X2.5-IN) | 10 | |
| 0S1588 | 22 BOLT (3/8-16X1.25-IN) | 16 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 4 | |
| 0S1608 | 24 BOLT (3/8-16X3.75-IN) | 4 | |
| 0S1617 | 25 BOLT (5/16-18X0.75-IN) | 10 | |
| 0T0055 | 26 BOLT (3/8-16X4.25-IN) | 8 | |
| 0304285 | 27 CONNECTOR | 4 | |
| 3B1915 | 28 BOLT (3/8-16X1.375-IN) | 4 | |
| 3E4352 | 29 WASHER-HARD (8.8X20.5X2.5-MM THK) | 10 | |
| 4P4460 | 30 GASKET | 4 | |
| 5M2894 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 1123540 | 32 SEAL-O-RING | 8 | |
| 6K5535 | 33 CLIP (SLOT) | 4 | |
| 6K5536 | 34 CLIP (TAB) | 4 | |
| 2385081 | 35 SEAL-O-RING | 1 | |
| 2385080 | 36 SEAL-O-RING | 4 | |
| 9L9132 | 37 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 9M4584 | 38 CONNECTOR | 1 | |
| 9S8752 | 39 NUT-FULL (3/8-16-THD) | 14 | |
| 9X6458 | 40 WASHER-HARD (10.2X22.5X3-MM THK) | 10 | |
| 4830365 | 41 BRACKET | 2 |
