System And Components
381-8570 LINES GP-AIR -LOWERAN ATTACHMENT
Group No: 381-8570
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C7909 | 1 ELBOW (AIR INLET) | 10 | |
| 7C7910 | 2 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 3 FLANGE | 12 | |
| 7N5080 | 4 GASKET-MANIFOLD | 12 | |
| 3485661 | 5 PLATE | 1 | |
| 2032163 | 6 SPACER (10.5X22.5X21.35-MM THK) | 4 | |
| 4289129 | 7 GASKET (SPIRAL WOUND) | 1 | |
| 2654433 | 8 COVER | 1 | |
| 2705323 | 9 MANIFOLD | 1 | |
| 2721604 | 10 COVER | 1 | |
| 3031541 | 11 SEAL-O-RING | 1 | |
| 0L2070 | 12 BOLT (3/8-16X2.25-IN) | 4 | |
| 0S0509 | 13 BOLT (3/8-16X0.75-IN) | 30 | |
| 0S1590 | 14 BOLT (3/8-16X2-IN) | 6 | |
| 0S1619 | 15 BOLT (3/8-16X3-IN) | 6 | |
| 1T0720 | 16 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 48 | |
| 2A4639 | 17 BOLT (3/8-16X1.625-IN) | 24 | |
| 3K0360 | 18 SEAL-O-RING | 1 | |
| 4S5898 | 19 SEAL-O-RING | 12 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 116 | |
| 5P2603 | 21 STUD-TAPERLOCK (3/8-16X1.57-IN) | 4 | |
| 6V5101 | 22 SEAL-O-RING | 12 | |
| 6W6672 | 23 SPACER (10.5X20X38-MM THK) | 6 | |
| 8T6762 | 24 PLUG-PIPE (1/2-14-THD) | 3 | |
| 8T6764 | 25 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S4185 | 26 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 4 |
