System And Components
283-6371 LINES GP-FUEL INJECTIONAN ATTACHMENT
Group No: 283-6371
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 8 | |
| 1081434 | GROMMET | 1 | |
| 4P0693 | 2 CLAMP AS | 4 | |
| 1081434 | GROMMET | 2 | |
| 4P0489 | 3 SPACER (11X25X26.8-MM THK) | 2 | |
| 6V4363 | 4 ELBOW | 1 | |
| 7C7677 | 5 TUBE AS | 12 | |
| 7C7678 | 6 TUBE AS | 12 | |
| 7C7682 | 7 ADAPTER-FUEL MANIFOLD (RH) | 1 | |
| 7C7683 | 8 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 7N6806 | 9 SEAL-RECTANGULAR | 4 | |
| 7W2122 | 10 CONNECTOR-PORT | 24 | |
| 9N4053 | 11 SPRING | 1 | |
| 0307977 | 12 ELBOW | 1 | |
| 1113389 | 13 TUBE AS | 1 | |
| 1145477 | 14 PLUNGER-VALVE | 1 | |
| 1189485 | 15 TUBE AS | 1 | |
| 1569753 | 16 MANIFOLD GP-FUEL (RH) | 1 | |
| 1569754 | 17 MANIFOLD GP-FUEL (LH) | 1 | |
| 2348728 | 18 TUBE AS | 1 | |
| 3866229 | 19 ELBOW AS | 2 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2501497 | ELBOW | 1 | |
| 2609152 | 20 VALVE-CHECK (FUEL) | 1 | |
| 2673398 | 21 TUBE AS | 1 | |
| 2749855 | 22 BRACKET | 1 | |
| 2837192 | 23 TUBE AS | 1 | |
| 0038581 | 24 TEE-UNION | 1 | |
| 0307959 | 25 TEE-FLARED | 1 | |
| 0L1143 | 26 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1352 | 27 BOLT (3/8-16X3.25-IN) | 2 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 1 | |
| 0T0065 | 29 BOLT (3/8-16X3.5-IN) | 2 | |
| 1D4539 | 30 BOLT (5/16-18X2.5-IN) | 1 | |
| 2P7636 | 31 CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2147568 | 32 SEAL-O-RING | 24 | |
| 2147566 | 33 SEAL-O-RING | 1 | |
| 1D4541 | 35 BOLT (5/16-18X3-IN) | 1 | |
| 5M2894 | 36 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5S0003 | 37 NUT (5/16-18-THD) | 1 | |
| 2385081 | 38 SEAL-O-RING | 5 | |
| 6V9012 | 39 CONNECTOR | 1 | |
| 7K3377 | 40 PIPE | 2 | |
| 9M1974 | 41 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9M4584 | 42 CONNECTOR | 2 | |
| 9S4182 | 43 PLUG (7/16-20-THD) | 1 | |
| 9S8752 | 44 NUT-FULL (3/8-16-THD) | 1 | |
| 1P7625 | 45 ELBOW | 1 | |
| 2385080 | 46 SEAL-O-RING | 3 |
