System And Components
153-1237 DRIVE GP-AUXILIARY -LOWER, LHS/N GZA1-UP
Group No: 153-1237
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2353546 | 1 SEAL-O-RING | 1 | |
| 5P0840 | 2 SEAL-O-RING | 1 | |
| 5L5840 | 3 WASHER (9.25X16.92X1.83-MM THK) | 1 | |
| 6V0405 | 4 SEAL-BONDED | 2 | |
| 7C3258 | 5 WASHER AS-THRUST | 1 | |
| 7N2047 | 5A DOWEL | 1 | |
| 7C3260 | 6 SHAFT | 1 | |
| 7E0275 | 7 GEAR-WATER PUMP DRIVE (69-TEETH) | 1 | |
| 7E6748 | 8 ADAPTER AS | 1 | |
| 8T6757 | 8A PLUG-PIPE | 1 | |
| 1275400 | 8B BUSHING | 1 | |
| 7N5246 | 9 WASHER-THRUST | 2 | |
| 1070777 | 11 SHAFT AS-PUMP DRIVE | 1 | |
| 1150591 | 11A BUSHING | 1 | |
| 5700440 | 12 ADAPTER AS | 1 | |
| 8T6759 | 12A PLUG-PIPE | 2 | |
| 1275400 | 12B BUSHING | 1 | |
| 1293948 | 13 SEAL-INTEGRAL | 1 | |
| 1386320 | 14 COVER | 1 | |
| 1448263 | 15 GEAR AS-IDLER (53-TEETH) | 1 | |
| 1409597 | 15A BUSHING | 1 | |
| 3B1915 | 16 BOLT (3/8-16X1.375-IN) | 6 | |
| 0T0055 | 17 BOLT (3/8-16X4.25-IN) | 1 | |
| 1A1460 | 18 BOLT (1/2-13X2-IN) | 3 | |
| 1T0720 | 19 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 5 | |
| 4B3388 | 20 BOLT (5/16-18X1.125-IN) | 4 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P8245 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 6K3771 | 23 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 12 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1D4572 | 25 BOLT (1/2-13X5.5-IN) | 2 | |
| 2594598 | 26 SEAL-O-RING | 2 | |
| 6V3348 | 27 SEAL-O-RING | 1 |
