System And Components
398-9294 MOUNTING GP-AIR CLEANERAN ATTACHMENT
Group No: 398-9294
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P0600 | 1 CLAMP-HOSE | 4 | |
| 8N5991 | 2 HOSE | 2 | |
| 1618071 | 4 HOSE AS | 2 | |
| 3154841 | 5 BRACKET AS (RH) | 1 | |
| 3154842 | 6 BRACKET AS (LH) | 1 | |
| 3154843 | 7 BRACKET AS | 2 | |
| 3770955 | 8 BRACKET | 2 | |
| 3770956 | 9 BRACKET | 2 | |
| 0S1571 | 10 BOLT (3/8-16X1.75-IN) | 6 | |
| 0S1590 | 11 BOLT (3/8-16X2-IN) | 10 | |
| 0S1591 | 12 BOLT (3/8-16X1.5-IN) | 8 | |
| 1984767 | 13 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 2N1287 | 14 ELBOW-FLARED | 2 | |
| 8M9024 | 15 WASHER-HARD (10.2X22.5X5-MM THK) | 8 | |
| 5P3426 | 16 ELBOW | 2 | |
| 6V5048 | 17 SEAL-O-RING | 2 | |
| 8M9124 | 18 WASHER (10X22.5X8-MM THK) | 32 | |
| 9S8752 | 19 NUT-FULL (3/8-16-THD) | 22 | |
| 9X6458 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 22 | |
| 9X8873 | 21 BOLT (1/2-13X2.25-IN) | 2 | |
| 0S1588 | 22 BOLT (3/8-16X1.25-IN) | 8 | |
| 2A4639 | 23 BOLT (3/8-16X1.625-IN) | 8 |
