System And Components
246-3274 STARTING MOTOR GP-AIRS/N SSM1-UP
Group No: 246-3274
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N4387 | 1 CASE AS-GEAR | 1 | |
| 4N4388 | 1A WASHER-SPECIAL | 1 | |
| 0091436 | 1B BEARING | 1 | |
| 4N4391 | 2 KEY-GEAR | 1 | |
| 4N4392 | 3 COVER AS-CASE | 1 | |
| 4N4393 | 3A SEAL-LIP TYPE | 1 | |
| 6J2244 | 3B SEAL-O-RING | 1 | |
| 6V1179 | 3C SEAL-O-RING | 1 | |
| 4N4394 | 4 GEAR-DRIVE (45-TEETH) | 1 | |
| 4N4397 | 5 COLLAR-DRIVE SHAFT | 1 | |
| 4N4400 | 6 RING-SHIFT | 2 | |
| 4N4402 | 7 SPACER (2.156X2.375X0.188-IN THK) | 1 | |
| 4N4403 | 8 SPRING-RING | 1 | |
| 4N4405 | 9 CLUTCH AS-DRIVE | 1 | |
| 4N4421 | 10 SHAFT-DRIVE | 1 | |
| 6D3787 | 11 BEARING-ROLLER | 1 | |
| 1055136 | 12 WASHER (9.92X16.67X0.79-MM THK) | 4 | |
| 1055137 | 13 PISTON | 1 | |
| 1055138 | 14 HOUSING | 1 | |
| 2463275 | 15 DEFLECTOR AS | 1 | |
| 2463276 | 16 PLUG | 4 | |
| 2463277 | 17 MOTOR AS | 1 | |
| 6V1320 | 17A SEAL-O-RING | 2 | |
| 7X4782 | 17B SEAL-O-RING | 2 | |
| 2463278 | 18 COVER | 1 | |
| 2463279 | 19 GASKET | 1 | |
| 2463280 | 20 CASE AS | 1 | |
| 6V1320 | 20A SEAL-O-RING | 1 | |
| 9X7357 | 20B SEAL-O-RING | 1 | |
| 2463284 | 21 HOUSING-MOTOR | 1 | |
| 2464452 | 22 GEAR AS | 1 | |
| 4N4386 | 22A RETAINER-PINION | 1 | |
| 4N4413 | 22B PINION-ROTOR | 1 | |
| 0520512 | 23 RING-RETAINING | 1 | |
| 3P0653 | 24 SEAL-O-RING | 1 | |
| 4N4390 | 25 WASHER-THRUST (0.797X1.50X0.125-IN THK) | 1 | |
| 5F8651 | 27 BALL BEARING | 1 | |
| 5P0537 | 28 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 6E5412 | 29 SEAL-O-RING | 1 | |
| 7B2742 | 30 BOLT (1/4-20X1.25-IN) | 9 | |
| 8F8544 | 31 BOLT (3/8-16X6.25-IN) | 4 | |
| 8T6757 | 32 PLUG-PIPE | 2 | |
| 8T6763 | 33 PLUG-PIPE (1/4-18-THD) | 3 |
