System And Components
362-8364 TANK GP-EXPANSIONS/N DSE1-UP
Group No: 362-8364
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I4955 | 1 REGULATOR-TEMPERATURE (81-DEG C) | 1 | |
| 3410087 | 2 PLUG AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3489060 | 3 ELBOW | 1 | |
| 5257154 | 4 BONNET-OUTLET | 3 | |
| 3960405 | 5 PLUG AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3643533 | 6 TANK AS-EXPANSION | 1 | |
| 2M6471 | PLUG-CUP | 2 | |
| 3660714 | 7 HOUSING-REGULATOR | 1 | |
| 3696875 | 8 ELBOW AS | 2 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 6V7486 | CONNECTOR | 1 | |
| 3717641 | 9 HOSE AS | 1 | |
| 4882488 | 10 HOUSING | 1 | |
| 3931804 | 11 VALVE AS | 1 | |
| 7N7688 | FERRULE | 1 | |
| 9M5590 | BALL | 1 | |
| 4303262 | 12 HOSE AS | 1 | |
| 0S1573 | 13 BOLT (1/2-13X4-IN) | 1 | |
| 0S1588 | 14 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1608 | 16 BOLT (3/8-16X3.75-IN) | 2 | |
| 0S1619 | 17 BOLT (3/8-16X3-IN) | 4 | |
| 1440367 | 18 CLAMP-HOSE | 2 | |
| 1674407 | 19 SEAL-O-RING | 1 | |
| 1J9671 | 20 SEAL-O-RING | 1 | |
| 1K3113 | 21 SPACER (0.546X0.840X3.875-IN THK) | 1 | |
| 2287090 | 22 SEAL-O-RING | 1 | |
| 2385080 | 23 SEAL-O-RING | 1 | |
| 2416168 | 24 PLUG AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3139614 | 25 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218671 | 26 CONNECTOR AS | 1 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3K0360 | 27 SEAL-O-RING | 1 | |
| 3K8460 | 28 PLUG (1/2-20-THD) | 1 | |
| 3S9643 | 29 SEAL-LIP TYPE | 1 | |
| 4J5573 | 30 SEAL-O-RING | 1 | |
| 5M2894 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 5M6509 | 32 SEAL-O-RING | 3 | |
| 5P8245 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V6707 | 34 SEAL-O-RING | 1 | |
| 6V8398 | 35 SEAL-O-RING | 1 | |
| 6V8639 | 36 CONNECTOR | 1 | |
| 7X7958 | 37 CLAMP-HOSE | 2 | |
| 8F8544 | 38 BOLT (3/8-16X6.25-IN) | 1 | |
| 8S9191 | 39 BOLT (3/8-16X4-IN) | 5 | |
| 3779562 | 40 PLUG AS | 1 | |
| 3K8460 | PLUG (1/2-20-THD) | 1 | |
| 2918144 | SEAL-O-RING | 1 | |
| 5P1262 | 41 HOSE (19-CM) | ||
| 3027411 | 42 HOSE (19-CM) |
