System And Components
471-1768 LINES GP-AIR COMPRESSORS/N MLX1-UP
Group No: 471-1768
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E6369 | 1 BRACKET | 1 | |
| 3526494 | 2 ADAPTER AS | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3537953 | 3 GROMMET | 2 | |
| 3650581 | 4 CONNECTOR AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3664672 | 5 CONNECTOR AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2949072 | SEAL-O-RING | 1 | |
| 3717174 | 6 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3855772 | 7 ELBOW AS | 1 | |
| 6V8628 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4204450 | 8 BRACKET | 1 | |
| 4391862 | 9 ELBOW AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2949072 | SEAL-O-RING | 1 | |
| 4477009 | 10 HOSE AS-AIR | 1 | |
| 4477012 | 11 HOSE AS | 1 | |
| 4477273 | 12 BRACKET | 1 | |
| 4671109 | 13 HOSE AS | 1 | |
| 4711761 | 14 HOSE AS | 1 | |
| 4711766 | 15 VALVE AS | 2 | |
| 0S1571 | 16 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 17 BOLT (3/8-16X1.25-IN) | 2 | |
| 1947631 | 18 ELBOW | 1 | |
| 2287088 | 19 SEAL-O-RING | 1 | |
| 3B1915 | 20 BOLT (3/8-16X1.375-IN) | 2 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P7464 | 22 CLIP (SLOT) | 3 | |
| 5P7465 | 23 CLIP (TAB) | 3 | |
| 6V6609 | 24 SEAL-O-RING | 3 | |
| 6V7359 | 25 GROMMET (25-MM ID, 37-MM OD) | 3 | |
| 8C8408 | 26 ELBOW | 1 | |
| 8T1889 | 27 CLIP (SLOT) | 2 | |
| 8T1890 | 28 CLIP (TAB) | 2 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 30 WASHER-HARD (10.2X22.5X3-MM THK) | 5 |
