System And Components
489-3106 LINES GP-FUEL -RETURNS/N MLX1-UP
Group No: 489-3106
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2053988 | 1 CLAMP-HALF | 2 | |
| 2416158 | 2 PLUG | 1 | |
| 2501416 | 3 ELBOW | 1 | |
| 4502403 | 4 MANIFOLD GP-FUEL | 1 | |
| 4666584 | 5 HOSE AS | 1 | |
| 4712995 | 6 HOSE AS | 1 | |
| 4844612 | 7 BRACKET | 1 | |
| 4893093 | 8 HOSE AS | 1 | |
| 4893102 | 9 HOSE AS | 1 | |
| 4893103 | 10 HOSE AS | 1 | |
| 0336033 | 11 SEAL-O-RING | 1 | |
| 1K6872 | 12 LOCKNUT (1/2-13-THD) | 2 | |
| 2006345 | 13 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 14 STRAP-CABLE | 2 | |
| 2287093 | 15 SEAL-O-RING | 5 | |
| 2287102 | 16 SEAL-O-RING | 1 | |
| 2K3374 | 17 WASHER (10.3X31.8X12.7-MM THK) | 2 | |
| 2K4973 | 18 LOCKNUT (3/8-16-THD) | 3 | |
| 5C6565 | 19 BOLT (1/2-13X1.125-IN) | 1 | |
| 5G3676 | 20 GROMMET | 1 | |
| 5P7468 | 21 CLIP (SLOT) | 1 | |
| 5P7469 | 22 CLIP (TAB) | 1 | |
| 5P7701 | 23 SEAL-O-RING | 2 | |
| 6V4589 | 24 SEAL-O-RING | 1 | |
| 6V5050 | 25 SEAL-O-RING | 2 | |
| 6V8714 | 26 CONNECTOR | 2 | |
| 6V9002 | 27 ELBOW | 1 | |
| 6V9005 | 28 ELBOW | 2 | |
| 7G3228 | 30 GROMMET | 1 | |
| 7V6234 | 31 PLATE | 1 | |
| 7X0295 | 32 BOLT (3/8-16X5.25-IN) | 2 | |
| 8L2779 | 33 SEAL-O-RING | 2 | |
| 8L2786 | 34 SEAL-O-RING | 4 | |
| 8T1889 | 35 CLIP (SLOT) | 1 | |
| 8T1890 | 36 CLIP (TAB) | 1 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4835 | 38 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T7087 | 40 GROMMET (34-MM ID) | 1 | |
| 8T9379 | 41 BOLT (3/8-16X4.25-IN) | 1 | |
| 8T9386 | 42 CONNECTOR | 1 | |
| 9S4185 | 43 PLUG (3/4-16-THD) | 1 | |
| 9S8005 | 44 PLUG (3/4-16-THD) | 2 |
