System And Components
536-9113 LINES GP-FUEL -RETURNS/N MLX1-UP
Group No: 536-9113
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 8 | |
| 2053988 | 2 CLAMP-HALF | 2 | |
| 3956552 | 3 GUARD | 2 | |
| 5286634 | 4 HOSE AS | 1 | |
| 5369114 | 5 HOSE AS | 1 | |
| 0314155 | 6 LOCKNUT (5/16-18-THD) | 1 | |
| 1314863 | 7 ELBOW | 1 | |
| 2006345 | 8 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 9 STRAP-CABLE | 2 | |
| 2074499 | 10 PLATE-COVER | 1 | |
| 2287092 | 11 SEAL-O-RING | 2 | |
| 2287093 | 12 SEAL-O-RING | 3 | |
| 2B0858 | 13 PLUG-PIPE | 1 | |
| 5C6565 | 14 BOLT (1/2-13X1.125-IN) | 1 | |
| 5P4116 | 15 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 5P7468 | 16 CLIP (SLOT) | 2 | |
| 5P7469 | 17 CLIP (TAB) | 2 | |
| 6V5729 | 18 LOCKNUT (7/16-14-THD) | 1 | |
| 6V9853 | 19 ELBOW | 1 | |
| 7C0257 | 20 PLATE | 2 | |
| 7X0278 | 21 BOLT (5/16-18X4-IN) | 1 | |
| 7X0589 | 22 WASHER-HARD (12X28.5X5-MM THK) | 1 | |
| 8C6877 | 23 BOLT (7/16-14X1.75-IN) | 1 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T5360 | 26 WASHER (12X22.5X2.5-MM THK) | 1 | |
| 8T7087 | 27 GROMMET (34-MM ID) | 2 |
