System And Components
359-5434 WIRING GP-TRANSMISSIONS/N MLX1-UP
Group No: 359-5434
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I1418 | 1 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 1342252 | 2 SENSOR GP-TEMPERATURE (8-VOLT)(TRANSMISSION OIL) | 1 | |
| 1342252 | 2A SENSOR GP-TEMPERATURE (8-VOLT)(TORQUE CONVERTER OIL) | 1 | |
| 3045687 | 3 CONTROL GP-UNPROGRAMMED (POWER TRAIN) | 1 | |
| 3097923 | 4 COVER | 1 | |
| 3122648 | 5 BRACKET | 1 | |
| 3134613 | 6 SENSOR AS-LIQUID LEVEL (TRANSMISSION OIL) | 1 | |
| 3831393 | GROMMET | 1 | |
| 3181181 | 7 SENSOR GP-SPEED (MAGNETIC)(ENGINE) | 1 | |
| 3261631 | 8 HARNESS AS-SENSOR (OUTPUT SPEED) | 1 | |
| 3447389 | 9 SENSOR AS-PRESSURE (MAIN RELIEF) | 1 | |
| 4734017 | 10 BRACKET AS | 1 | |
| 1787023 | BOSS (M10X1.5X30-MM) | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 8R1496 | SPACER (10X20X29-MM THK) | 4 | |
| 3595452 | 11 HARNESS AS-CONTROL (POWER TRAIN) | 1 | |
| 3646643 | 12 HARNESS AS-TRANSMISSION | 1 | |
| 3646649 | 13 HARNESS AS-CONTROL (SPEED SENSOR) | 1 | |
| 3846687 | 14 HARNESS AS-POWER (TRANSMISSION) | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 2 | |
| 1046202 | 16 CLIP (LADDER) | 1 | |
| 1325789 | 18 CLIP (LADDER) | 16 | |
| 2147568 | 21 SEAL-O-RING | 3 | |
| 2B2694 | 23 BOLT (5/16-18X2-IN) | 4 | |
| 3H0107 | 27 SEAL-O-RING | 1 | |
| 4L6454 | 29 BOLT (3/8-16X1-IN) | 18 | |
| 4P7428 | 30 CLIP (LADDER) | 12 | |
| 4P7429 | 31 CLIP (LADDER) | 2 | |
| 4P7581 | 32 CLIP (LADDER) | 10 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6D5801 | 34 LOCKNUT (8-32-THD) | 8 | |
| 7K1181 | 37 STRAP-CABLE | 3 | |
| 7U4892 | 38 SCREW (8-32X0.75-IN) | 8 | |
| 7X0623 | 40 WASHER (10.5X21X2-MM THK) | 19 | |
| 8T4136 | 41 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4224 | 42 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T9655 | 43 MOUNT-ISOLATION | 8 | |
| 9M1974 | 44 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9N0869 | 45 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 8T6912 | 47 BOLT (M8X1.25X50-MM) | 4 | |
| 3132476 | 49 SCREW-SPECIAL | 2 | |
| 2486981 | 50 SCREW-MACHINE (M3X0.5X22-MM) | 4 | |
| 1892512 | 51 PLATE | 1 | |
| 1809900 | 52 CAP AS | 1 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 5P7958 | SLEEVE-CABLE SPLICE | 1 | |
| 1799392 | LANYARD | 1 | |
| 0966166 | 53 WASHER-HARD (4.5X9X1-MM THK) | 1 | |
| 5P7970 | 55 NUT (M8X1.25-THD) | 2 | |
| 3S2093 | 56 STRAP-CABLE | 49 | |
| 9X4391 | 57 PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X5615 | SEAL (INTERFACE, 70-PIN) | 2 | |
| 8T8737 | 58 PLUG-SEAL | 70 | |
| 4P8134 | 59 CLIP (LADDER) | 1 |
