System And Components
541-2260 LINES GP-HYDRAULICS/N MLX1-UP
Group No: 541-2260
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T5224 | 1 GAUGE-PRESSURE (HYDRAULIC OIL) | 1 | |
| 1013121 | 2 SPACER (10.5X25X25-MM THK) | 1 | |
| 1592313 | 3 VALVE-CHECK | 5 | |
| 3606691 | 4 BRACKET AS | 1 | |
| 3916451 | 5 MANIFOLD | 1 | |
| 4205594 | 6 HOSE AS | 1 | |
| 4205595 | 7 HOSE AS | 1 | |
| 4205596 | 8 HOSE AS | 1 | |
| 4205597 | 9 HOSE AS | 1 | |
| 4205598 | 10 HOSE AS | 1 | |
| 4205599 | 11 HOSE AS | 1 | |
| 5387437 | 12 ELBOW | 5 | |
| 2D6235 | 13 LOCKNUT (1/4-20-THD) | 2 | |
| 2K4973 | 14 LOCKNUT (3/8-16-THD) | 2 | |
| 3J1907 | 15 SEAL-O-RING | 1 | |
| 3J7354 | 16 SEAL-O-RING | 6 | |
| 3S8665 | 17 CLIP (LOOP) | 2 | |
| 4J5477 | 18 SEAL-O-RING | 10 | |
| 4L9337 | 19 BOLT (3/8-16X1.5-IN) | 1 | |
| 5M3062 | 20 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P1075 | 21 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P7468 | 22 CLIP (SLOT) | 2 | |
| 5P7469 | 23 CLIP (TAB) | 2 | |
| 5S7382 | 24 BOLT (3/8-16X1.375-IN) | 2 | |
| 6V0545 | 25 GROMMET | 2 | |
| 6V8398 | 26 SEAL-O-RING | 1 | |
| 6V8628 | 27 ELBOW | 5 | |
| 6V9873 | 28 CONNECTOR | 1 | |
| 7J8611 | 29 ELBOW-PIPE | 1 | |
| 7J9108 | 30 SEAL-O-RING | 1 | |
| 7X0264 | 31 BOLT (1/4-20X2.5-IN) | 2 | |
| 8C6866 | 32 CONNECTOR | 5 | |
| 8T4205 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T8915 | 35 BOLT (3/8-16X3.25-IN) | 1 | |
| 9S4182 | 36 PLUG (7/16-20-THD) | 1 |
