System And Components
459-6511 LINES GP-VENT -SEPARATE CIRCUIT AFTERCOOLERAN ATTACHMENT
Group No: 459-6511
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8723 | 1 ELBOW | 1 | |
| 3172845 | 2 CLIP | 1 | |
| 5160347 | 3 TUBE AS-WATER | 1 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 1 | |
| 0S1590 | 5 BOLT (3/8-16X2-IN) | 1 | |
| 3676011 | 6 CONNECTOR AS | 1 | |
| 6D7128 | SEAL-O-RING | 1 | |
| 8C6868 | CONNECTOR | 1 | |
| 3256994 | 7 CLIP (SLOT) | 3 | |
| 3256995 | 8 CLIP (TAB) | 3 | |
| 3537956 | 9 GROMMET | 3 | |
| 5F4899 | 10 BOLT (3/8-16X5.5-IN) | 1 | |
| 6D7128 | 11 SEAL-O-RING | 2 | |
| 9S8752 | 12 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 6V6609 | 14 SEAL-O-RING | 1 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 1 | |
| 5139302 | 16 HOSE AS | 1 | |
| 8T7934 | 17 WASHER-HARD (11X21X5-MM THK) | 1 |
