System And Components
486-9867 SENSOR GP-PRESSUREAN ATTACHMENT
Group No: 486-9867
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2978049 | 1 GROMMET | 1 | |
| 3762275 | 3 BLOCK-SENSOR | 3 | |
| 3829950 | 4 BRACKET | 2 | |
| 3829951 | 5 TUBE AS-FUEL | 1 | |
| 3829952 | 6 TUBE AS-OIL | 1 | |
| 3829953 | 7 TUBE AS-OIL | 1 | |
| 0L2070 | 9 BOLT (3/8-16X2.25-IN) | 3 | |
| 1653931 | 10 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1590 | 12 BOLT (3/8-16X2-IN) | 2 | |
| 1984766 | 13 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 2147566 | 14 SEAL-O-RING | 6 | |
| 2287088 | 15 SEAL-O-RING | 6 | |
| 1653929 | 16 BOLT (3/8-16X1.5-IN) | 2 | |
| 3256994 | 17 CLIP (SLOT) | 1 | |
| 3256995 | 18 CLIP (TAB) | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6V8628 | 20 ELBOW | 4 | |
| 6V8647 | 21 CONNECTOR | 2 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 8 |
