System And Components
454-2245 LINES GP-WATER -AFTERCOOLER, JACKET WATERAN ATTACHMENT
Group No: 454-2245
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W0530 | 1 RING-RETAINING | 4 | |
| 4W0531 | 2 RETAINER | 8 | |
| 7C9597 | 3 FLANGE | 2 | |
| 8N0386 | 4 FLANGE | 1 | |
| 0910081 | 5 SPACER (10.5X20X10-MM THK) | 1 | |
| 2301072 | 6 GASKET | 2 | |
| 2648272 | 7 CLAMP AS | 2 | |
| 2982378 | 8 ADAPTER | 2 | |
| 3619367 | 9 CONNECTOR | 1 | |
| 3735443 | 10 ELBOW | 2 | |
| 3757972 | 11 TUBE | 2 | |
| 3883917 | 12 FLANGE | 2 | |
| 3886443 | 13 RING | 2 | |
| 3960405 | 14 PLUG AS | 4 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 4460380 | 15 ELBOW | 1 | |
| 4530772 | 16 ELBOW | 1 | |
| 4530773 | 17 TUBE | 1 | |
| 4618691 | 18 ORIFICE | 1 | |
| 5171666 | 19 BRACKET | 2 | |
| 6V8801 | 20 NUT (3/8-16-THD) | 2 | |
| 0L1352 | 21 BOLT (3/8-16X3.25-IN) | 2 | |
| 1653931 | 22 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1588 | 23 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 4 | |
| 1653929 | 25 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 14 | |
| 0T0065 | 27 BOLT (3/8-16X3.5-IN) | 3 | |
| 1674407 | 28 SEAL-O-RING | 7 | |
| 1932120 | 29 GROMMET | 2 | |
| 1A2029 | 30 BOLT (3/8-16X1.125-IN) | 2 | |
| 4N1320 | 31 GASKET (ADAPTER) | 2 | |
| 4P5085 | 32 COVER | 2 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 28 | |
| 6V1867 | 34 CLIP (SLOT) | 2 | |
| 6V1868 | 35 CLIP (TAB) | 2 | |
| 6V5066 | 36 SEAL-O-RING | 1 | |
| 8T1919 | 37 SEAL-O-RING | 6 | |
| 9S8752 | 38 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 39 WASHER-HARD (10.2X22.5X3-MM THK) | 14 | |
| 5B4399 | 41 SEAL-O-RING | 2 |
