455-8674 WIRING GP-ENGINEAN ATTACHMENT

Group No: 455-8674

Part Number	Part Name	Qty
9X3495	1 CLIP AS	1
9X6772	2 STRAP-CABLE	16
2123426	3 SENSOR GP-SPEED (ENGINE)	1
2450522	4 BRACKET	1
2450523	5 BRACKET	2
2613856	6 BRACKET AS	1
8C3334	RIVET-TUBULAR	2
2616847	7 ADAPTER	2
2659033	8 SENSOR GP-SPEED (CRANKSHAFT POSITION)	1
2659033	8A SENSOR GP-SPEED (CAMSHAFT POSITION)	1
2786469	9 GROMMET	7
2883783	10 SENSOR-TEMPERATURE (ENGINE COOLANT)	1
2883783	10A SENSOR-TEMPERATURE (AIR INLET MANIFOLD, SECONDARY)	1
2883783	10B SENSOR-TEMPERATURE (AIR INLET MANIFOLD, PRIMARY)	1
2883783	10C SENSOR-TEMPERATURE (ENGINE OIL)	1
2883783	10D SENSOR-TEMPERATURE (SEPARATE CIRCUIT AFTERCOOLER)	1
3496231	11 BRACKET	1
3497374	12 SENSOR GP-PRESSURE (ATMOSPHERIC PRESSURE)	1
3497374	12A SENSOR GP-PRESSURE (CRANKCASE)	1
3497377	13 SENSOR GP-PRESSURE (AIR INLET MANIFOLD, SECONDARY)	1
3497377	13A SENSOR GP-PRESSURE (AIR INLET MANIFOLD, PRIMARY)	1
3535441	14 ADAPTER-ELBOW	1
3559605	15 ADAPTER	1
3591828	16 BRACKET AS	1
3664683	17 ADAPTER	4
3724759	18 BRACKET	2
4152431	19 SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, RH)	1
4152431	19A SENSOR GP-EXHAUST TEMPERATURE (3-PIN)(TURBOCHARGER INLET, LH)	1
4255669	20 BRACKET	1
4558676	21 HARNESS GP-ENGINE (RAIL, LH)	1
4558679	22 HARNESS GP-ENGINE (RH)	1
0966166	23 WASHER-HARD (4.5X9X1-MM THK)	2
0L1143	24 BOLT (3/8-16X2.5-IN)	2
0S0509	25 BOLT (3/8-16X0.75-IN)	6
1653931	26 BOLT (3/8-16X1.75-IN)	2
0S1588	27 BOLT (3/8-16X1.25-IN)	16
0S1590	28 BOLT (3/8-16X2-IN)	1
1653929	29 BOLT (3/8-16X1.5-IN)	4
0S1594	30 BOLT (3/8-16X1-IN)	13
0S1595	31 BOLT (1/2-13X1.25-IN)	1
0S1620	32 BOLT (1/2-13X0.75-IN)	1
0T0573	33 BOLT (3/8-16X2.75-IN)	1
1003237	34 GROMMET	1
1046202	35 CLIP (LADDER)	1
1153071	36 CLIP AS-CONNECTING (6-PIN)	2
1240289	37 CLIP	1
1325789	38 CLIP (LADDER)	1
1391398	39 CLIP (LOOP)	2
1751367	40 SPACER (8.8X16X10-MM THK)	1
1790469	41 SPACER (11X20X40-MM THK)	1
1984766	42 WASHER-HARD (11X25X10-MM THK)	2
1A9579	43 BOLT (5/16-18X1.5-IN)	1
2147566	44 SEAL-O-RING	4
2159632	45 SPACER (12X20X20-MM THK)	4
2190669	46 SEAL-O-RING	2
2287100	47 SEAL-O-RING	5
2287101	48 SEAL-O-RING	2
2385080	49 SEAL-O-RING	3
2973218	50 CLIP (LADDER)	1
2A4639	51 BOLT (3/8-16X1.625-IN)	1
2B2694	52 BOLT (5/16-18X2-IN)	1
2M3403	53 BOLT (3/8-16X3.63-IN)	4
2N3162	54 SCREW-MACHINE (10-24X1.25-IN)	2
3118802	55 SPACER (10.5X19X57-MM THK)	4
3309739	56 ADAPTER	2
3398937	57 CLIP (LOOP)	1
3505720	58 CLIP (LADDER)	2
3523966	59 CLIP (LADDER)	1
3523968	60 CLIP (LADDER)	3
3535439	61 CONNECTOR	1
3E4352	62 WASHER-HARD (8.8X20.5X2.5-MM THK)	1
3K0360	63 SEAL-O-RING	2
4P7429	64 CLIP (LADDER)	1
4P7581	65 CLIP (LADDER)	3
4P8134	66 CLIP (LADDER)	2
5M2894	67 WASHER-HARD (10.2X18.5X2.5-MM THK)	40
5P8245	68 WASHER-HARD (13.5X25.5X3-MM THK)	2
6V1581	69 CLIP (SLOT)	4
6V1582	70 CLIP (TAB)	4
6V1612	71 BOLT (1/2-13X9.75-IN)	2
6V6609	72 SEAL-O-RING	1
7C4354	73 CLIP	1
7D1649	74 WASHER-HARD (13.5X32X5-MM THK)	2
7G5984	75 CLIP (TAB)	7
7G5985	76 CLIP (SLOT)	7
8M2770	77 CLIP (LOOP)	2
8T1887	78 CLIP (SLOT)	1
8T1888	79 CLIP (TAB)	1
9M8406	80 CLIP (LOOP)	1
9S4185	81 PLUG (3/4-16-THD)	2
9S8752	82 NUT-FULL (3/8-16-THD)	8
9X6458	83 WASHER-HARD (10.2X22.5X3-MM THK)	19
