System And Components
524-4912 WIRING GP-ENGINES/N MR4204-223
Group No: 524-4912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N2126 | 1 CONNECTOR (THERMOCOUPLE) | 12 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 9X6772 | 4 STRAP-CABLE | 43 | |
| 4224704 | 5 SPACER (10.5X20X60-MM THK) | 1 | |
| 1834274 | 7 BRACKET | 1 | |
| 2341644 | 9 CONTROL GP-ENGINE MONITORING (THERMOCOUPLE) | 1 | |
| 5189109 | SOFTWARE GP-GENERATOR SET (THERMOCOUPLE) | 1 | |
| 2450522 | 10 BRACKET | 1 | |
| 2450523 | 11 BRACKET | 3 | |
| 2566453 | 12 SENSOR-TEMPERATURE (2-PIN)(ENGINE COOLANT TEMPERATURE) | 1 | |
| 2566453 | 12A SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 2566453 | 12B SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 2566453 | 12C SENSOR-TEMPERATURE (2-PIN)(ENGINE OIL BLOCK INLET) | 1 | |
| 2566453 | 12D SENSOR-TEMPERATURE (2-PIN)(AIR INLET) | 1 | |
| 2613856 | 13 BRACKET AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 7C2644 | CLIP | 1 | |
| 5221641 | 14 SENSOR GP-SPEED (CAMSHAFT POSITION) | 1 | |
| 5221641 | 14A SENSOR GP-SPEED (CRANKSHAFT POSITION) | 1 | |
| 2786469 | 15 GROMMET | 6 | |
| 2818666 | 16 THERMOWELL | 2 | |
| 3496231 | 17 BRACKET | 1 | |
| 3603693 | 18 PLUG (3/4-16-THD) | 1 | |
| 3832990 | 19 SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 12 | |
| 4849878 | 20 SENSOR GP-PRESSURE (COMPRESSOR INLET AIR, RH) | 1 | |
| 4849878 | 20A SENSOR GP-PRESSURE (COMPRESSOR INLET AIR, LH) | 1 | |
| 4849879 | 21 SENSOR GP-PRESSURE (TURBOCHARGER INLET, LH) | 1 | |
| 4849879 | 21A SENSOR GP-PRESSURE (TURBOCHARGER INLET, RH) | 1 | |
| 5017844 | 22 WIRING GP-ENGINE (PRESSURE CONTROL) | 1 | |
| 5256717 | 23 WIRING GP-ENGINE (RAIL, LH) | 1 | |
| 5256720 | 24 WIRING GP-ENGINE (RAIL, RH) | 1 | |
| 5256733 | 25 HARNESS AS-ENGINE (PYROMETER) | 1 | |
| 5358805 | 26 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 4 | |
| 0L1143 | 27 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1351 | 28 BOLT (3/8-16X0.875-IN) | 1 | |
| 0L1352 | 29 BOLT (3/8-16X3.25-IN) | 1 | |
| 0L2070 | 30 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 31 BOLT (3/8-16X0.75-IN) | 5 | |
| 1653928 | 32 BOLT (3/8-16-THD) | 12 | |
| 0S1590 | 33 BOLT (3/8-16X2-IN) | 2 | |
| 1653929 | 34 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 35 BOLT (3/8-16X1-IN) | 12 | |
| 0S1615 | 36 BOLT (1/4-20X0.75-IN) | 4 | |
| 0S1620 | 37 BOLT (1/2-13X0.75-IN) | 2 | |
| 0T0102 | 39 BOLT (3/8-16X0.625-IN) | 1 | |
| 1153073 | 40 CLIP AS-CONNECTING | 1 | |
| 1189901 | 41 SPACER (12X20X10-MM THK) | 1 | |
| 1275447 | 42 SPACER (10.5X20X12-MM THK) | 2 | |
| 1325789 | 43 CLIP (LADDER) | 5 | |
| 1336934 | 44 SPACER (11X20X25-MM THK) | 1 | |
| 1391398 | 45 CLIP (LOOP) | 4 | |
| 1751367 | 48 SPACER (8.8X16X10-MM THK) | 1 | |
| 5P8937 | 49 COMPOUND-JOINT (THERMAL) | ||
| 1B7182 | 50 BOLT (5/16-18X1.25-IN) | 1 | |
| 2147566 | 51 SEAL-O-RING | 4 | |
| 2159632 | 52 SPACER (12X20X20-MM THK) | 1 | |
| 2385080 | 53 SEAL-O-RING | 3 | |
| 2771873 | 54 CLIP (LADDER) | 1 | |
| 2B2694 | 55 BOLT (5/16-18X2-IN) | 1 | |
| 2M3403 | 56 BOLT (3/8-16X3.63-IN) | 4 | |
| 3118802 | 57 SPACER (10.5X19X57-MM THK) | 4 | |
| 3523964 | 59 CLIP (LADDER) | 1 | |
| 3523966 | 60 CLIP (LADDER) | 2 | |
| 3523967 | 61 CLIP (LADDER) | 2 | |
| 3523968 | 62 CLIP (LADDER) | 4 | |
| 3523969 | 63 CLIP (LADDER) | 1 | |
| 3B1915 | 64 BOLT (3/8-16X1.375-IN) | 2 | |
| 3E4352 | 65 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 4P7581 | 66 CLIP (LADDER) | 5 | |
| 4P8134 | 67 CLIP (LADDER) | 12 | |
| 5M2894 | 68 WASHER-HARD (10.2X18.5X2.5-MM THK) | 42 | |
| 5P0537 | 69 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P8245 | 70 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 5V9221 | 71 SPACER (13.8X25X25-MM THK) | 1 | |
| 6V1581 | 72 CLIP (SLOT) | 5 | |
| 6V1582 | 73 CLIP (TAB) | 5 | |
| 6V1612 | 74 BOLT (1/2-13X9.75-IN) | 2 | |
| 6V6609 | 75 SEAL-O-RING | 5 | |
| 7G5984 | 76 CLIP (TAB) | 6 | |
| 7G5985 | 77 CLIP (SLOT) | 6 | |
| 7X0288 | 78 BOLT (3/8-16X1.625-IN) | 1 | |
| 8T4223 | 79 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4835 | 80 BOLT (1/2-13X2-IN) | 1 | |
| 8X6439 | 81 SPACER (18X32X101-MM THK) | 1 | |
| 9M1974 | 82 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S8752 | 83 NUT-FULL (3/8-16-THD) | 6 | |
| 9X6458 | 84 WASHER-HARD (10.2X22.5X3-MM THK) | 11 | |
| 7X0334 | 85 BOLT (1/2-13X5-IN) | 1 | |
| 1653929 | 86 BOLT (3/8-16X1.5-IN) | 2 | |
| 5T6374 | 87 SPACER (11X20X40-MM THK) | 1 |
